Video
Video Outputs: One decode configurable to DVI-I or
Composite (BNC)
Error concealment and de-blocking filter.
Video aspect format: 4x3 or 16x9 (or custom mode via
API command)
Back to back frame accurate playback from same output
port
Standard Definition (SD) Decode
MPEG 2 SD: MP@ML
MPEG 2 SD: 422P@ML
AVC/H.264: [email protected]
High Definition (HD) Decode
MPEG 2 HD: MP@HL
AVC/H.264 HD: [email protected] and [email protected]
Audio
Audio Outputs:
S/PDIF digital audio (RCA female)
Unbalanced analog stereo audio (1/8î female)
Dolby Digital AC-3: Bit rates up to 640kbps. Sample
rates of 32, 44.1 and 48KHz Downmix to 2 channel
Dolby Pro Logic
MPEG 1 and MPEG 2 Layer I, II and III (MP3) 2.0: Bit
rates up to 448kbps (Layer I), 384kbps (Layer II) or
320kbps (Layer III)
Sample rates of 16, 22.05, 24, 32, 44.1 and 48KHz
Single channel, dual channel, joint stereo and stereo
modes.
AAC-LC MPEG-2 and MPEG-4:
Bit rates up to 384kbps.
Sample rates of 7.35, 8, 11.025, 12, 16, 22.05, 24,
32, 44.1 and 48KHz
SignEdje Player
Storage: 8GB solid state storage or 160GB internal hard
drive
Adtec optimized POSIX compliant embedded
Linux 2.6 kernel
Power: 12 VDC
Environmental: 0 to 90 Degrees Fahrenheit, Less than
70% RH, Non-Condensing
Communications and Control
Ethernet 10/100 (RJ-45):
Half Duplex, Full Duplex, Auto Negotiate
Ethernet Protocols:
Telnet, FTP, Adtec command API.
Serial Communications:
2-RS232 (38400-115,200K, 8, 1 N)
Options & Accessories
DVI-D/DVI-D Cable:
Used with TV Standard Display Targets.
DVI/HDMI Cable:
Used with TV Standard Display Targets.
DVI-I/VGA Cable:
Used with PC Standard Display Targets.
DVI/RGBHV Cable:
Used with TV Standard Display Targets.
DVI/Component Cable:
Used with TV Standard Display Targets.
EdjeShelf:
Holds 3 signEdje units, power supplies.
Specifications
signEdje
TM
Digital Signage Player
DC Input:
12 VDC
Composite Video Out:
Analog Video Interface. BNC
Digital Video Out:
Digital Video Interface. Cables purchased separately
Audio Left:
Unbalanced analog audio left channel (RCA)
Audio Right:
Unbalanced analog audio right channel (RCA)
Audio SPDIF:
Digital audio (RCA) configurable as Compressed (for 5.1 AC-3 audio) or
Uncompressed (PCM 2 channel).
Parallel Cntl I/O:
Parallel port used for input or output control.
Com1 (not API port):
RS-232 terminal monitor for communicating with the internal host
motherboard for diagnostics.
Com2 (API):
RS-232 Adtec API control and status terminal port.
Ethernet:
10/100BaseT Ethernet RJ-45.
