Specifications

OTMN-II

MetroNode 4-Output Compact, Modular, Scaleable Fiber Deep

FTTC Optical Node

Optical Input Range (Standard) . . . . . . . . . . . . . . . . . . . . . . . .-4dBm to +3dBm
Optical Input Range (Optional High Sensitivity) . . . . . . . . . . .-8dBm to -3dBm
Forward Frequency Range . . . . . . . . . . . . . . . . . . . . . . . . . . .54MHz to 870MHz or 85MHz to 870MHz (optional 1GHz top end)
Reverse Frequency Range . . . . . . . . . . . . . . . . . . . . . . . . . . .5MHz to 42MHz or 5MHz to 65MHz
Forward Frequency Response . . . . . . . . . . . . . . . . . . . . . . . .<±0.75dB to 870MHz, ±1.0dB from 54MHz to 1GHz
Reverse Frequency Response . . . . . . . . . . . . . . . . . . . . . . . .<±0.75dB 5MHz to 42MHz or 5MHz to 65MHz
Output Level (Forward) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .+50dBmV @ 550MHz (Each of four outputs)

With -1dBm optical input, 10dB slope to 870MHz, and Transmitter
OMI @ 3.2%. (1GHz option is 12dB slope and +48dBmV output)

Distortion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>62dB CSO/CTB @ above output and +3dBm optical input.

Carrier loading (77 channels) to 550MHz. Simulated data loading
@ -6dB from 550MHz to 870MHz (or optional 1GHz)

Carrier to Noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>53dB @ -1dBm optical or greater

Carrier loading (77 channels) to 550MHz

In/Out Return Loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>16dB - All ports 1 through 4 (as applicable) from 54-870MHz

>14dB - All ports 1 through 4 (as applicable) from 54MHz-1GHz
Port 5 (power port) >15dB to 65MHz with optional return port configuration

Return Laser Output Power(s) . . . . . . . . . . . . . . . . . . . . . . . . . 1.5, 2.0, 2.5 and 3.0mW ±0.5mW
Return Path NP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Range over 41dB NPR is >15dB measured with 10dB of fiber

(With DFB Return Laser & OT LP-OR-300 return band receiver)

Return Path NPR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Range over 41dB NPR is as follows:(With DFB Return Laser) >13dB

measured with 10dB of fiber as above and both bands moving together.

Return Path NPR Threshold . . . . . . . . . . . . . . . . . . . . . . . . . .< -57dBmV/Hz
Operating Temperature Range . . . . . . . . . . . . . . . . . . . . . . . .-40°C to +65°C
Gain Variation vs. Temperature . . . . . . . . . . . . . . . . . . . . . . . .<±1dB typical

<±1.5dB Max
<±1.8dB REVERSE

AC Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76.5 Watts @ 60 VAC @ 50-60Hz; (45VAC to 90VAC).

Will withstand overvoltage to 140 VAC

Internal Test Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .See unit diagram for functional description and location
Hum Modulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>60dB @ 15 Amps AC current from any one port 7MHz to 25MHz

>65dB @ 15 Amps AC current from any one port 25MHz to 870MHz

Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-1/2"W x 8-1/4"D x 9"H

N - # Outputs/Diplexer

0: 4-Output; 42/54
MHz
1: 4-Output; 65/85
MHz

XYZ - Return Transmitter(s)

000:

No Return Transmitter

X =

0 (Single Transmitter)
1 (Dual Transmitter)
2 (1 TX; Status Monitoring TR)
3 (Dual TX; Split Feeder

Return)

Y =

2 (3mW DFB NTSC; 1310nm)
3 (3mW DFB PAL; 1310nm)
4 (1.5mW FP NTSC; 1310nm)
5 (1.5mW FP PAL; 1310nm)
6 (2.5mW DFB NTSC; 1550nm)
7 (2.5mW DFB PAL; 1550nm)
8 (2mW FP NTSC; 1310nm)
9 (2mW FP PAL; 1310nm)

Z =

A (Filter Bypass)
B (10MHz High Pass Filter

AB - Receiver (s)

00: Single RX (std)

01: Dual RX w/ABS

02: Split Band Dual RX

03: High Sensitivity RX

CD - 5th Port Return

00: No 5th Port Return

01: 5th Port Return

EF - Status Monitoring

00: Without Status

01: With Status

/OPT - Other Options

/P: Powdercoating

/GHz: 1 GHz Bandwidth

Other options as

required (contact facto-

1) Plug-In Equalizers

Model #9508xxL

(Individual 870 MHz Equalizer; xx = value 00 to 22)

Model #950800K

(15 EQ 870 MHz Equalizer Kit; values 08 to 22)

Model #951015L

(Individual 1 GHz Equalizer; 15 dB)

2) Plug-In Attenuators

(19 Values; Specify 0dB to 18 dB in 1 dB increments.)

Model #9518xxL

(Individual Attenuator Pads; xx = value 00 to 18)

Model #951800K

(19 Pads Attenuator Kit; values 00 to 18)

*Typical 870 MHz OTMN-II node shipped with 10dB slope & +50dBmV output/port @ - 1 dBm optical
in. 1 GHz nodes ship with 12 dB slope and +48 dBmV output port @ -1dBm optical in.
Optional Pad & EQ accessories needed for different performance values.

OTMN -

OTMN-II Model Number Configuator
