SRT Series
Indoor 5-1000 MHz Taps
SRT-4A Specifications
Tap Value
8 11 14 17 20 23 26 29 32 35
Insertion Loss (dB)
5 MHz:
*
3.5
1.8
1.0 0.7 0.7
0.5
0.5 0.5
0.5
300 MHz:
*
3.5
1.7
1.0 0.7 0.6
0.5
0.5 0.5
0.5
400 MHz:
*
4.0
2.1
1.5 1.1 0.8
0.7
0.7 0.7
0.7
500 MHz:
*
4.5
2.3
1.8 1.3 1.2
1.0
0.8 0.8
0.8
600 MHz:
*
5.5
2.5
2.0 1.5 1.3
1.1
1.0 1.0
1.0
1000 MHz:
*
6.5
3.0
2.5 1.8 1.5
1.3
1.3 1.3
1.3
Return Loss (In/Out) (dB)
5-10 MHz:
18
18
16
18
18
18
18
18
18
18
10-50 MHz:
20
20
18
20
20
20
20
20
20
20
50-450 MHz:
18
18
18
20
20
20
20
20
20
20
450-750 MHz:
18
18
18
18
18
18
18
18
18
18
750-1000 MHz:
16
16
16
16
16
16
16
16
16
16
Return Loss (Tap) (dB)
5-10 MHz:
18
10-750 MHz:
20
750-1000 MHz:
18
Isolation Tap-to-Tap (dB)
5-10 MHz:
22
10-450 MHz:
26
450-750 MHz:
25
750-1000 MHz:
22
Isolation Out-to-Tap (dB)
5-400 MHz:
-
24
27
31
33
37
38
40
43
45
400-500 MHz:
-
24
25
26
31
34
37
40
42
45
500-600 MHz:
-
21
21
23
27
29
31
35
38
40
600-1000 MHz:
-
20
20
22
24
26
27
27
30
30
Tap Tolerance (± dB)
5-450 MHz:
1.0 1.0
1.0
1.0 1.0 1.0
1.0
1.0 1.0
1.0
450-750 MHz:
1.0 1.0
1.5
2.0 2.0 2.0
2.0
2.0 2.0
2.0
750-1000 MHz:
1.5 1.5
2.0
2.0 2.0 2.0
2.0
2.0 2.0
2.0
SRT-8A Specifications
Tap Value
11 14 17 20 23 26 29 32 35
Insertion Loss (dB)
5-50 MHz:
*
3.5
1.9
1.2 0.8 0.8
0.7
0.7 0.7
50-450 MHz:
*
4.0
2.3
1.5 1.0 0.9
0.8
0.8 0.8
450-750 MHz:
*
4.2
2.4
1.8 1.2 1.0
1.0
1.0 1.0
750-1000 MHz:
*
4.5
2.5
2.0 1.4 1.2
1.0
1.0 1.0
Return Loss (In/Out) (dB)
5-10 MHz:
18
18
16
18
18
18
18
18
18
10-50 MHz:
20
20
18
20
20
20
20
20
20
50-450 MHz:
20
20
18
20
20
20
20
20
20
450-750 MHz:
18
18
18
18
18
18
18
18
18
750-1000 MHz:
16
16
16
16
16
16
16
16
16
Return Loss (Tap) (dB)
5-10 MHz:
18
10-750 MHz:
18
750-1000 MHz:
18
Isolation Tap-to-Tap (dB)
5-10 MHz:
22
10-450 MHz:
26
450-750 MHz:
25
750-1000 MHz:
22
Isolation Out-to-Tap (dB)
5-10 MHz:
-
30
28
36
36
38
38
38
38
10-50 MHz:
-
30
28
35
36
35
36
36
36
50-450 MHz:
-
26
25
32
33
32
32
32
32
450-750 MHz:
-
24
24
30
30
30
30
30
30
750-1000MHz:
-
24
24
26
26
28
28
28
30
Tap Tolerance (± dB)
5-450 MHz:
1.0 1.0
1.0
1.0 1.0 1.0
1.0
1.0 1.0
450-750 MHz:
1.5 1.5
1.5
1.5 1.5 1.5
1.5
1.5 1.5
750-1000 MHz:
2.0 2.0
2.0
2.0 2.0 2.0
2.0
2.0 2.0
Ordering Information
Model Stock
#
Description
SRT-2a
1942
Directional Tap, 2 Output 5-1000 MHz, In-Line Style, Values: 4,8,11,14,17,20,23,26,29,32 dB
SRT-4a
1944
Directional Tap, 4 Output 5-1000 MHz, In-Line Style, Values: 8,11,14,17,20,23,26,29,32,35 dB
SRT-8a
1948
Directional Tap, 8 Output 5-1000 MHz, In-Line Style, Values: 11,14,17,20,23,26,29,32,35 dB
