Features
Response A graduated 1-turn panel potentiometer is used
to optimize the AC response for various load
parameters.
High Voltage LED Front panel red LED illuminates when the high
voltage is on.
Mechanical
Dimensions 85 mm H x 205 mm W 325 mm D
(3.3” H x 8.1” W x 12.8” D)
Weight 2 kg (4.4 lb)
HV Connector SHV Connector
BNC Connectors Amplifier Input, Voltage Monitor, Current Monitor,
Digital Enable
Operating Conditions
Temperature 0°C to 40°C (32°F to 104°F)
Relative Humidity To 85%, noncondensing
Altitude To 2000 meters (6561.68 ft.)
Electrical
Input Power 90 to 265 V AC, at 50/60 Hz
Output Power 24 V DC, regulated at 1.75A maximum
HV Cable 2 m, 30.8 pF per foot
Supplied Accessories
Operator’s Manual PN: 23446
AC Adapter PN: L5215R
HV Output Connector
(SHV Mating
Connector) PN: 43874R
Optional
Accessories None
Note
The output cable supplied with this instrument uses a coaxial cable
that has 30.8 pF/ft of capacitance at 1 kHz nominal. This cable
capacitance must be factored in as a portion of the load and will reduce
slew rates and large signal bandwidth. In applications that require
maximum performance it is suggested that the supplied high voltage
coaxial cable be kept as short as possible to reduce capacitance.
Another option is to cut the coaxial cable short and add two break out
leads (one for shield [ground] and one for the center conductor) for the
connection to load.
Model 2210 Specifications
Performance
Output Voltage
Range 0 to ±1 kV DC or peak AC
Output Current
Range 0 to ±20 mA DC or ±40 mA peak for 5 ms
minimum
Input Voltage Range 0 to ±10 V DC or peak AC
Input Impedance 10 kW, nominal
DC Voltage Gain 100 V/V
DC Voltage Gain
Accuracy Better than 0.5% of full scale
DC Offset Voltage Less than 1 V
Output Noise Less than 30 mV rms*
Slew Rate
(10% to 90%, typical) Greater than 150 V/µs
Large Signal
Bandwidth (-3 dB) DC to greater than 40 kHz
Small Signal
Bandwidth (-3dB) DC to greater than 100 kHz
Settling Time to 1% Less than 30 µs for 0 to 1 kV step
Internal Capacitance
(HV Output) 300 pF
Automatic Power
Limit Limits internal power dissipation for protection
from overheating
Stability
Drift with Time Less than 300 ppm/hr, noncumulative
Drift with Temp Less than 180 ppm/°C
Voltage Monitor
Ratio 1/100th of the high voltage output
Noise 5 mV rms
DC Accuracy Better than 0.5% of full scale
Current Monitor
Ratio 0.2 V/mA
DC Accuracy Better than 2% of full scale
*Measured using the true rms feature of the Hewlett Packard Model 34401A digital multimeter Copyright © 2012 TREK, INC. All specifications are subject to change. 1303/JRB
