PERFORMANCE FEATURES GENERAL
PROBE
NOTE: The Model 706B is
designed to make electrostatic
voltage measurements only!
Certification
Measurement Range Range Switch Power Requirements
0 to +1 kV or -1 kV DC A two-position switch is used to Two (2) 9-volt alkaline batteries.
(switch selectable). select the measurement range of
either
0 to +1 kV or 0 to -1 kV. Operating Time
Accuracy 10 hours after battery replacement.
Better than 0.5% of full scale. TEST/READ Switch
In the TEST position, if the digital Operating Conditions
display indicates a value lower than Temperature
1100, the batteries should be 5 °C to 35 °C.
Relative Humidity replaced. In the READ position, the
Recommended Probe-to-Surface To 85%, noncondensing. measurements are displayed.
Separation Distance
1 mm to 5 mm. Voltage Display Dimensions
3½ digit liquid crystal display. 39 mm H x 130 mm W x 134 mm D,
Trek Model 701P-76S Probe Range (1.6² H x 5.2² W x 5.3²L).
Dimensions 0 to ±1000 V.
8.7 mm diameter x 70 mm L
Resolution Weight
(0.35² diameter x 2.75² L). 1 V. 455 g (1 lb), with batteries.
Zero Offset
Caution: The metallic components of Less than ±1 count. Ground Receptacle
the probe are driven to the measured Sampling Rate The g reen banana jack must be
surface voltage level with a current 3 readings per second. connected to ground to maintain
capability of ±0.5 milliamperes. These measurement accuracy .
metallic surfaces should not be
connected to ground or touched during
Power On/Off
operation.
A two-position toggle switch.
Cable Length
1830 mm (72"). To ensure safety, the Model 706B
should never be used to perform
TREK, INC. certifies that each Model 706B
Aperture Size (oval shaped) measurements of “hard” voltage is tested and calibrated to specifications
using measurement equipment traceable
3.18 mm W x 6.35 mm L sources or voltage sources
to the National Institute of Standards and which can deliver currents high (0.125² W x 0.25² L).
Technology. enough to cause harmful shocks
or personal injury.
Aperture Orientation
RoHS and CE compliant.
Side viewing.
Model 706B Included Accessories Certification (cont.)
Item Part No.
Portable Electrostatic Voltmeter . . . . . . . . . . . . . . . . . . . . 706B
Operator's Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23389
Two (2) (9 V) Alkaline Batteries . . . . . . . . . . . . . . . . . . . F1003R
Ground Patch Cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . N9044
RoHS compliant
Low Voltage Safety Compliance (IEC 61010)
Overvoltage Category
CAT I: Peripheral level outputs (less than 60 volts).
Pollution Category
Degree 1: Operate in environments where no
pollution or only dry, nonconductive pollution occurs.
Model 10/40A Specifications
Model 706B Specifications
Copyright Ó 2011 TREK, INC.
All specifications are subject to change.
1122/DEC
All specifications are at a probe-to-surface separation of 3 mm unless otherwise noted.
