Model 347 Specifications
Performance
Measurement Range 0 to ±20 kV DC or peak AC
Measurement Accuracy Better than ±0.1% of full scale, referred to
the voltage monitor
Speed of Response
(10% to 90%) Less than 200 µs for 1 kV step. Less than
5 ms for 20 kV step change
Full Signal Bandwidth DC to better than 25 Hz
Stability
Drift with Time Less than 100 ppm/hour, noncumulative
Drift with Temperature Less than 100 ppm/˚C
Voltage Monitor
Output A buffered output provides a low-voltage
replica of the measured voltage
Ratio 1/100th of the measured voltage
Output Noise Less than 20 mV rms*
Output Impedance Less than 0.1 W
Voltage Display
Voltage Display 4 ½ digit LED display
Range 0 to V ±19.99 k
Resolution 1 V
Zero Offset ±2 counts, referred to the voltage monitor
Sampling Rate 3 readings per second
Features
High Voltage Ready LED LED indicator illuminates when the Model
341B is ready to make high-voltage
measurements
High Voltage ON-OFF Two-position toggle switch that turns on
and off the high-voltage power supply
inside the instrument
Zero Control A 10-turn control to null offsets or other
zero errors that occur within the system
Mechanical
Dimensions 230 mm H x 441 mm W x 432 mm D
(9.06” H x 17.36” W x 17” D)
Weight 17 kg (37 lb)
Voltage Monitor
Output Connector BNC connector
Ground Receptacle Green binding post
Operating Conditions
Temperature 0°C to 40°C (32°F to 104°F)
Relative Humidity To 90%, noncondensing
Altitude To 2000 m (6561.68 ft.)
Probe-to-Surface
Separation 3 mm ±1mm (recommended)
Electrical
AC Line Cord
Receptacle Standard 3-prong with integral fuse holder
Line Voltage Factory set for one of two ranges: 90 to 127
V AC or 180 to 250 V AC, at 48 to 63 Hz
Power ON/OFF Two-position rocker switch that turns ON
and OFF the main power to the instrument
Supplied Accessories
Operator’s Manual PN: 23306
Line Cord PN: N5002 (for 90 to 127 V AC)
PN: Determined by the geographical
destination (for 180 to 250 V AC)
Optional Accessories
Probes Please refer to Page 1
Probe Line Driver
(required when used
with the 341B-1 and
an extended cable
length) Model: 3460-1
Probe Extension
Cable (from the 341B
to the probe) PN: 17218, Model 3450EC Probe Extension
Cable
Full-Rack Mount Kit Model 603RA (19-inch)
