Trek PD06087 High-Voltage Power Amplifier - Manual (Page 2)

Features (cont.)
Dynamic Adjustment Graduated 1-turn panel potentiometer is used
to optimize the AC response for various load
parameters
Current Limit/Trip Switch selectable for either limit or trip.
Graduated 1-turn panel potentiometer is used
to adjust limit or trip level from 0 to ±20 mA
Out of Regulation
Status Illuminates and a TTL low is provided when unit
fails to produce required HV output for 500 ms
or more such as during current limit or short
circuit conditions
Trip Status Illuminates and a TTL low is provided when the
high-voltage output is disabled due to the
output current exceeding the current trip level,
the detection of a high-voltage supply fault or
the removal of the top cover
Mechanical
Dimensions 190 mm H x 432 mm W 417 mm D
(7.5” H x 17” W x 16.4” D)
Weight 14.9 kg (31 lb)
HV Connector Alden high-voltage connector
BNC Connectors Amplifier Input, Voltage Monitor, Current Monitor,
Remote High Voltage ON/OFF, Out of Regulation
Status, Fault/Trip Status
Operating Conditions
Temperature 0°C to 40°C (32°F to 104°F)
Relative Humidity To 85%, noncondensing
Altitude To 2000 meters (6561.68 ft.)
Electrical
Line Voltage Factory Set for one of two ranges:
104 to 127 V AC or 180 to 250 V AC,
either at 48 to 63 Hz
AC Line Receptacle Standard AC line connector with integral fuse
holder
Power Consumption 680 VA, maximum
Supplied Accessories
Operators’ Manual PN: 23413
HV Output Cable PN: 43406
Line Cord, Spare
Fuses PN: N5002; s
destination elected per geographic
Optional Accessories
High-voltage output
cable PN: 43421 (5 meter)
High-voltage output
cable PN: 43422 (10 meter)
High-voltage output
cable PN: 43423 (20 meter)
19-in Rack Mount Kit Model 608RA (EIA hole spacing)
19-in Rack Mount Kit Model 608RAJ (JIS hole spacing)
Model PD06087 Specifications
Performance
Output Voltage
Range 0 to ±5 kV DC or peak AC
Output Current
Range 0 to ±20 mA DC or peak AC
Input Voltage Range 0 to ±5 V DC or peak AC
Input Impedance 20 kW, nominal
DC Voltage Gain 1000 V/V
DC Voltage Gain
Accuracy Better than 0.1% of full scale
DC Offset Voltage Less than ±2 V
Output Noise Less than 5 V rms*
Slew Rate
(10% to 90%, typical) Greater than 500 V/µs
Large Signal
Bandwidth
(1% distortion) DC to greater than 15 kHz
Small Signal
Bandwidth (-3dB) DC to greater than 20 kHz
Settling Time (to 1%) Less than 100 µs for a 0 to 5 kV step
Stability
Drift with Time Less than 100 ppm/hr, noncumulative
Drift with Temp Less than 100 ppm/°C
Voltage Monitor
Ratio 1/1000th of the high-voltage output
DC Accuracy Better than 0.1% of full scale
DC Offset Voltage Less than ±3 mV
Output Noise Less than 20 mV rms*
Output Impedance 47 W
Current Monitor
Ratio 0.5 V/ mA
DC Accuracy Better than 1% of full scale
Offset Voltage Less than ±10 mV
Output Noise Less than 30 mV rms*
Bandwidth (-3dB) DC to greater than 5 kHz
Output Impedance 47 W
Features
High-Voltage On/Off
Local Individual push-button switch
Remote (TTL
compatible input) TTL high (or open) turns off high-voltage output.
TTL low turns on high-voltage output.
Fault Status A BNC provides a TTL low when the PD05034
is out of regulation for greater than 100 ms
Copyright ã 2012 TREK, INC. All specifications are subject to change. 1250/JRB
Measurement and Power Solutions TM
*Measured using the true rms feature of the HP Model 34401A digital multimeter
