Model 800 Specifications
Performance
Measurement Range 0 to ±100 V DC or peak AC
Measurement Accuracy
Voltage Monitor Output Better than ±0.1% of full scale
Voltage Display Better than ±0.1% of reading, ±1 digit
(referred to measured input)
Speed of Response
(10% to 90%) Less than 3.5 ms for 100 V step
Large Signal Bandwidth
(-3 db) DC to greater than 100 Hz for 200 V pp
Input Resistance Greater than 1 X 10 16 W
Input Capacitance -15 Less than 1 X 10 F
Voltage Monitor
Output Two BNC outputs provide buffered low-
voltage replica of the measured voltage
Ratio 20:1 of the measured to output voltage
and 1:1 representation
Output Voltage Less than ±5 mV
Output Noise Less than 10 mV rms
Output Impedance Less than 0.5 W
Features
LCD Display Screen with
LED back-light 127 mm x 38 mm (5" x 1.5") screen
displays prompts and voltage
measurements with date and time
Display Resolution 240 x 64 pixels
Hold Mode Controlled by local pushbuttons or
remotely through HOLD BNC Connector
Zero Controlled by local pushbuttons or
remotely by applying a momentary (100
ms minimum) TTL low through a
designated BNC Connector
Null Offsets (Auto Null
Adjustment) Nulling of the input voltage and current is
necessary when the unit is first powered on,
or when the display prompts that an auto
null adjustment is necessary. Placing the
probe in a holster on the side of the unit
and pressing the NULL OFFSETS
pushbutton provides nullification of the
voltage offsets and the “leakage” currents,
which are dependent on environmental
conditions. An audio tone will signal when
the null offsets process is completed.
TEMP/RH Meter Connector A connector receives an input from an
optional thermo hygrometer (Omega Model
HH311) and enables the Model 800 to
display environmental data on the LCD
screen.
USB Communications Port 4-pin Type B connector
Mechanical
Dimensions 10.2 cm H x 31.6 cm W x 24.1 cm D
(4” H x 12.5” W x 9.5” D)
Weight 2.5 kg (5.5 lb)
BNC Connectors Two Voltage Monitors (
Hold
Reset 20:1, 1:1)
Ground Receptacle Threaded ground stud
Power ON/OFF A momentary push-button
Probe Connector
Location Front panel
Operating Conditions
Temperature 10°C to 35°C (50°F to 95°F)
Relative Humidity 0 to 80%, noncondensing
Altitude To 2000 m (6561.68 ft.)
Electrical
AC Line Cord
Receptacle Selected per geographic destination
Line Voltage 12 V AC, ±10% @ 1 A
DC Connector 2.1 mm DC power plug
Accessories
Operator’s Manual
with software PN: 23338
Ground Cord PN: N9044
AC Line Cord Selected per geographic destination
USB Cable 1.8 m (6 ft) PN: BA103
Probe Model 800P PN: 17491
Probe Tips 1.27 mm gold plated rounded tip electrode
Additional tips can be customized in various
other sizes to cater to a wide field of
applications; please contact the factory for
more information
Carrying Case PN: 47032
Note: All specifications measured with a 5-minute warmup time. Copyright ã 2013 TREK, INC. All specifications are subject to change. 1307/JRB
