RIEDEL SFPs-MADI User Manual
Madi sfp modules
Riedel Communications GmbH & Co. KG
|
Uellendahler Str. 353
|
42109 Wuppertal
|
Germany
www.riedel.net
16.09.2013
|
Rev 1.0
|
Subject to change without notice. Errors and omissions excepted.
MADI SFP modules
This document itemise all SFPs used in MADI applications
in Artist, PMX, RockNet and MediorNet.
Extensive testing is conducted by Riedel to ensure 100% compatibility and
perfect operation of all offered SFP modules when used with our products.
We can therefore not guarantee trouble-free operation of our products,
when SFP modules other than the ones offered by Riedel are used.
General
Riedel
Matchcode
SFP-MADI-
MM-850-14-125Mbps
SFP-MADI-
MM-1310-7,5-155Mbps
SFP-MADI-
SM-1310-19-155Mbps
Riedel
Item
1990047
1990002
1990003
Products
MADI-108-G2 SET, PMX 2004, PMX 2008, RN.334.MD RP, MN-MA2-EO
Connector
Duplex LC
Duplex LC
Duplex LC
Mode
multi-mode
multi-mode
single-mode
Data Rate
125
Mbps
155
Mbps
155
Mbps
Distance
*1
2
km
*2
2
km
*2
15
km
*3
Opt. Budget
14
dB
7.5
dB
19
dB
Power
Consumption
1.4
W
1.4
W
1.4
W
Temperature
0 ... +70
°C
-10 ... +70
°C
0 ... +70
°C
TX
Power Out
-10 ... -4
dBm
*2
-23.5 ... -14
dBm
*2
-15 ... -8
dBm
*3
Extinction Ratio
9
dB
10
dB
8.2
dB
Wavelength
830 ... 860
nm
1270 ... 1380
nm
1261 ... 1360
nm
Spectral Width
0.85
nm
--
4
nm
Jitter
1
ns
--
--
RX
Power In
-24 ... 0
dBm
-31 ... -8
dBm
-34 ... 0
dBm
Wavelength
770 ... 860
nm
1260 ... 1600
nm
1260 ... 1600
nm
LOS Asserted
-45
dBm
-47
dBm
-45
dBm
LOS Deasserted
-24
dBm
-32
dBm
-34
dBm
LOS Hysteresis
--
1
dB
1
dB
*1
The maximum distance can vary with the number of connectors, patch fields and attenuation on the line.
*2
50/125 μm fiber
*3
9/125 μm fiber
