RIEDEL SFPs-Artist User Manual

Artist sfp modules

background image

Riedel Communications GmbH & Co. KG

|

Uellendahler Str. 353

|

42109 Wuppertal

|

Germany

www.riedel.net

16.09.2013

|

Rev 1.0

|

Subject to change without notice. Errors and omissions excepted.

Artist SFP modules

This document itemise all SFPs used in Artist and PMX applications.

Extensive testing is conducted by Riedel to ensure 100% compatibility and

perfect operation of all offered SFP modules when used with our products.

We can therefore not guarantee trouble-free operation of our products,

when SFP modules other than the ones offered by Riedel are used.

General

Riedel

Matchcode

ART-Z-SFP-CPU-

MM-850-8,5-1,25Gbps

ART-Z-SFP-CPU-

MM-1310-10-1,25Gbps

ART-Z-SFP-CPU-

SM-1310-10,5-1,25Gbps

ART-Z-SFP-PMX-

SM-TX1310/RX1550-18-155Mbps

ART-Z-SFP-PMX-

SM-TX1550/RX1310-18-155Mbps

Riedel

Item

1090002

1090003

1090004

1090083

1090084

Products

CPU-128F G2 SET

PMX 2004, PMX 2008

Connector

Duplex LC

Duplex LC

Duplex LC

Simplex LC

Simplex LC

Mode

multi-mode

multi-mode

single-mode

single-mode

single-mode

Data Rate

1.25

Gbps

1.25

Gbps

1.25

Gbps

155

Mbps

155

Mbps

Distance

*1

500

m

*2

2

km

*2

10

km

*3

30

km

*3

30

km

*3

Opt. Budget

8.5

dB

10

dB

10.5

dB

18

dB

18

dB

Power

Consumption

0.9

W

0.9

W

0.9

W

0.7

W

0.7

W

Temperature

0 ... +70

°C

0 ... +70

°C

0 ... +70

°C

0 ... +70

°C

0 ... +70

°C

TX

Power Out

-9.5 ... -4

dBm

*2

-9 ... -1

dBm

*2

-9.5 ... -3

dBm

*3

-14 ... -8

dBm

*3

-14 ... -8

dBm

*3

Extinction Ratio

9

dB

9

dB

9

dB

8.2

dB

8.2

dB

Wavelength

830 ... 860

nm

1270 ... 1355

nm

1270 ... 1355

nm

1261 ... 1360

nm

1480 ... 1580

nm

Spectral Width

0.85

nm

4

nm

2.5

nm

4

nm

3

nm

Jitter

227

ps

227

ps

227

ps

--

--

RX

Power In

-18 ... 0

dBm

-19 ... -1

dBm

-20 ... -3

dBm

-32 ... 0

dBm

-32 ... 0

dBm

Wavelength

770 ... 860

nm

1260 ... 1610

nm

1260 ... 1610

nm

1480 ... 1600

nm

1260 ... 1360

nm

LOS Asserted

-35

dBm

-35

dBm

-35

dBm

-45

dBm

-45

dBm

LOS Deasserted

-18

dBm

-19

dBm

-20

dBm

-32

dBm

-32

dBm

LOS Hysteresis

--

--

--

--

--

*1

The maximum distance can vary with the number of connectors, patch fields and attenuation on the line.

*2

50/125 μm fiber

*3

9/125 μm fiber
