Riedel ACTOR
Intelligent Trunking Interface for 3rd Party Intercoms
The new Riedel Actor is a revolutionary solution that
allows intelligent trunking between Riedel Artist Digital
Matrix Intercom systems and third party intercom
installations. It provides seamless communications
between both systems. This includes all point-to-point
connections with port alpha transfer and tally as well as
group calls and conferences (partylines).
WAN
Director Director Director
Trunk
Navigator
Trunk
Navigator
ARTIST
VoIP-108 G2
Main Redundant
Audio in/out (Analog)
Audio in/out (AES/Digital)
3rd Party Matrix 3rd Party Control Panel
ARTIST
VoIP-108 G2
Audio in/out (Analog)
Audio in/out (AES/Digital)
ACTOR
ACTOR
WAN
3rd Party Control Panel 3rd Party Matrix
Trunking Master
Trunk Navigator
System Overview
All available audio connections are handled in an intelligent
way. Multiple calls to one destination use only one trunk line.
Also calls from one source to multiple destinations will use
only one trunk line. This enables an efficient use of available
audio bandwidth. ACTOR operates as an interface between
the two systems and shows the local resources of the Riedel
Artist Digital Matrix Intercom to the 3rd party system as if
they were an integral part of that system and vice versa.
ACTOR is self-configuring and auto-senses the amount of
available audio connections. It understands the “language”
and functions of third party intercoms. This way Riedel’s
ACTOR helps to secure previous intercom investments
and enables customers to proceed in future intercom
installations with a Artist Digital Matrix Intercom solution
from Riedel.
