PRELIMINARY SPEC SHEET
Diesel Generator Set – 3,000 ekW – 60 Hz
PRELIMINARY 4 of 5 2/6/2006
Information contained in this publication may be considered confidential. www.cat-ElectricPower.com
Preliminary Package Dimensions without Radiator
1840 Frame Package Dimensions
Length 5,894.8 mm 227.7 in
Width 1,650.5 mm 65.0 in
Height 2,248.5 mm 88.5 in
Weight 18,800 kg 41,500 lbs
Note: Do not use for installation design.
Consult factory for final configuration.
1860 Frame Package Dimensions
Length 6,004.8 mm 236.4 in
Width 1,650.5 mm 65.0 in
Height 2,248.5 mm 88.5 in
Weight 18,800 kg 41,500 lbs
Note: Do not use for installation design.
Consult factory for final configuration.
Materials and specifications are subject to change without notice.
3020 Frame Package Dimensions
Length 6,009.4 mm 236.58 in
Width 1957.3 mm 77.05 in
Height 2276.4 mm 89.62 in
Weight 20,089 kg 44,288.6 lbs
Note: Do not use for installation design.
Consult factory for final configuration.
Generator Technical Data
C175-16, Standby, 60Hz, 1800 RPM 480 Volts (std) 480 Volts (opt) 4,160 Volts (opt)
Heat Rejection
Heat rejection to atmosphere from generator 105.59 kW 6,010.2 Btu/min 95.98 kW 5,463.2 Btu/min 99.17 kW 5,644.7 Btu/min
Generator
Motor starting capability @32.5% voltage dip, 0.4 PF
Frame
Winding
Temperature Rise
7070 skVA
1846
Random
150
°C 302°F
8233 skVA
1866
Form
150
°C 302°F
9604 skVA
1846
Form
150
°C 302°F
Generator temperature rise is based on a 40 o C ambient per NEMA MG1-32.
12,470 Volts (opt) 13,200 Volts (opt) 13,800 Volts (opt)
144.7 kW 8,228.9 Btu/min 144.7 kW 8,228.9 Btu/min 144.7 kW 8,228.9 Btu/min
7548 skVA
3020
Form
130
°C 266°F
6924 skVA
3020
Form
130
°C 266°F
7505 skVA
3020
Form
130
°C 266°F
Discretion is recommended when distributing.
Materials and specifications are subject to change without notice.
