PRELIMINARY SPEC SHEET
Diesel Generator Set – 3,000 ekW – 60 Hz
PRELIMINARY 2 of 5 2/6/2006
Information contained in this publication may be considered confidential. www.cat-ElectricPower.com
Discretion is recommended when distributing.
Specifications
CAT Generator
Excitation ….………………………………..IE
Pitch………………………………………...2/3
Number of poles …………………………….. 4
Number of bearings ……………………….… 2
Insulation …...… UL 1446 Recognized Class H
IP rating ……………………… Drip Proof IP23
Alignment …………………….. closed coupled
Overspeed capability - % of rated ………... 125
Wave form ………….... Less than 5% deviation
Paralleling kit/Droop transformer ….... Standard
Telephone Influence Factor ……… Less than 50
Harmonic distortion ……………... Less than 5%
CAT Digital Voltage Regulator
Microprocessor based
VAR/PF control …………...……...….. Standard
Direct 3 Phase sensing with selectable volts/Hz
Communicates with EMCP 3
Programmable operating characteristics
Voltage regulation … Less than +/- 0.25%
(steady
state), Less than +/- 1% (no load to full load)
Compatible with self-excited, PMG, and IE
CAT Diesel Engine
C175-16, 4-stroke-cycle water-cooled diesel
Bore – mm ………….……….. 175 mm (6.89 in)
Stroke – mm ………….…...… 220 mm (8.66 in)
Displacement – L ………. 84.6 L (5165.1 cu. in)
Compression ratio ………………………. 15.3:1
Aspiration ……………..………….…...…SCAC
Fuel system ………………………Common Rail
Governor type ………..Caterpillar ADEM
TM A4
CAT EMCP3 Control Panels
• EMCP 3.1 (Standard)
• EMCP 3.2 & 3.3 (Optional)
• 24 Volt DC control
•
Generator instruments designed to meet
UL/CSA/CE/UL508A
•
Integral generator terminal box
•
Single location for customer connection
•
MODBUS isolated data link (RS-485 half-duplex)
supports serial communication at data rate up to 115.2
kbaud
•
Auto start/stop control
•
True RMS metering, 3-phase
•
Digital indication for:
- RPM
- Operating hours
- Oil pressure
- Coolant temperature
- System DC volts
- L-L Volts, L-N Volts, phase amps, Hz
- ekW, kVA, kVAR, kW-hr, %kW, PF
•
Shutdowns with indicating lights for:
- Low oil pressure
- High coolant temperature
- Low coolant level
- Overspeed
- Emergency stop
- Failure to start (over crank)
•
Programmable protective relay functions:
- Under and over voltage
- Under and over frequency
- Reverse power
- Overcurrent (phase & total)
•
Programmable kW level relay
CAT Control Options
• Programmable annunciator (local and
remote or both) (2 max)
•
Spare discrete I/O (16 in/8 out) (1 max)
• Generator temperature
monitor/protection (stator & bearing)
•
Engine temperature monitor/protection
Materials and specifications are subject to change without notice.
