349E L (LC-FIX) Mass Boom Lift Capacities – Americas
LoadPointHeight LoadatMaximumReach LoadRadiusOverFront LoadRadiusOverSide
Boom–6.55m(21'6") Counterweight–9.0mt(9.9t) Bucket–None
Stick–M3.0UB(9'10") Shoes–900mm(35")triplegrouser
1.5 m/5.0 ft 3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft
m
ft
9.0m kg
30.0 ft lb
7.5m kg *11550 10900 *10000 *10000 7.67
25.0 ft lb *22,050 *22,050 24.87
6.0m kg *13000 10750 *9700 8600 8.53
20.0 ft lb *28,350 23,100 *21,400 19,150 27.85
4.5m kg *20900 *20900 *16200 14650 *13850 10400 *10750 7700 *9800 7600 9.07
15.0 ft lb *44,800 *44,800 *35,050 31,600 *30,150 22,350 *21,600 16,850 29.69
3.0m kg *25650 20900 *18450 13800 *15000 9950 12150 7500 *10250 7100 9.33
10.0 ft lb *55,100 45,150 *39,850 29,750 *32,500 21,400 26,050 16,150 *22,500 15,650 30.59
1.5m kg *22900 19700 *20200 13050 15700 9550 11900 7300 *11050 6900 9.34
5.0 ft lb *55,050 42,400 *43,650 28,150 33,800 20,550 25,600 15,750 *24,250 15,250 30.65
Ground
Line
kg *25950 19250 *20900 12650 15400 9250 11750 7200 11550 7050 9.10
lb *60,500 41,350 *45,300 27,200 33,100 19,950 25,450 15,550 29.86
–1.5m kg *17850 *17850 *27100 19200 *20500 12450 15250 9150 12550 7600 8.59
–5.0 ft lb *40,400 *40,400 *58,800 41,250 *44,400 26,850 32,800 19,700 27,650 16,800 28.16
–3.0m kg *29400 *29400 *24300 19400 *18700 12550 *14300 9250 *13450 8850 7.76
–10.0 ft lb *66,650 *66,650 *52,550 41,700 *40,400 27,050 *30,450 19,950 *29,650 19,600 25.35
–4.5m kg *19300 *19300 *14600 12950 *12900 11700 6.48
–15.0 ft lb *41,300 *41,300 *30,750 27,950 *28,300 26,200 20.99
Boom–6.55m(21'6") Counterweight–9.0mt(9.9t) Bucket–None
Stick–M2.5UB(8'2") Shoes–900mm(35")triplegrouser
1.5 m/5.0 ft 3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft
m
ft
9.0m kg
30.0 ft lb
7.5m kg *13050 11800 7.10
25.0 ft lb *28,900 26,600 22.99
6.0m kg *15350 15300 *13850 10700 *12700 9500 8.03
20.0 ft lb *33,300 32,900 *30,350 22,950 *27,950 21,150 26.19
4.5m kg *22750 22400 *17250 14550 *14600 10350 *12850 8350 8.60
15.0 ft lb *48,800 48,450 *37,250 31,350 *31,800 22,300 *28,250 18,400 28.14
3.0m kg *19300 13700 *15600 9950 12450 7750 8.87
10.0 ft lb *58,350 44,300 *41,750 29,550 *33,850 21,450 27,400 17,050 29.09
1.5m kg *20800 13100 15750 9600 12200 7550 8.88
5.0 ft lb *44,950 28,200 33,900 20,700 26,900 16,600 29.15
Ground
Line
kg *23950 19450 *21150 12750 15500 9350 12600 7750 8.63
lb *56,350 41,800 *45,800 27,450 33,350 20,200 27,800 17,050 28.33
–1.5m kg *18050 *18050 *26250 19500 *20300 12650 15450 9300 13850 8450 8.10
–5.0 ft lb *41,150 *41,150 *57,050 41,900 *43,950 27,300 33,250 20,100 30,550 18,650 26.52
–3.0m kg *28000 *28000 *22900 19800 *17900 12850 *14100 10050 7.20
–10.0 ft lb *61,000 *61,000 *49,600 42,550 *38,600 27,650 *31,000 22,250 23.52
–4.5m kg *16950 *16950 *12900 *12900 5.79
–15.0 ft lb *36,050 *36,050 *28,100 *28,100 18.72
*Indicatesthattheloadislimitedbyhydraulicliftingcapacityratherthantippingload.Theaboveloadsareincompliancewithhydraulicexcavatorliftcapacity
standardISO10567:2007.Theydonotexceed87%ofhydraulicliftingcapacityor75%oftippingload.Weightofallliftingaccessoriesmustbedeductedfromthe
aboveliftingcapacities.Liftingcapacitiesarebasedonthemachinestandingonafirm,uniformsupportingsurface.Theuseofaworktoolattachmentpointto
handle/liftobjects,couldaffectthemachineliftperformance.
AlwaysrefertotheappropriateOperationandMaintenanceManualforspecificproductinformation.
