349E L Hydraulic Excavator Specifications
Bucket and Stick Forces
HD Reach Boom Mass Boom
6.9 m (22'8") 6.55 m (21'6")
Stick R3.9TB R3.35TB M3.0UB M2.5UB
(12'10") (11'0") (9'10") (8'2")
kN (lbf) kN (lbf) kN (lbf) kN (lbf)
For CW-55
General Duty
Bucket Digging Force (ISO) 220 (49,500) 220 (49,500) – –
Stick Digging Force (ISO) 172 (38,700) 186 (41,800) – –
Bucket Digging Force (SAE) 204 (45,900) 204 (45,900) – –
Stick Digging Force (SAE) 169 (38,000) 182 (40,900) – –
Heavy Duty
Bucket Digging Force (ISO) – – 262 (58,900) 262 (58,900)
Stick Digging Force (ISO) – – 202 (45,400) 228 (51,300)
Bucket Digging Force (SAE) – – 237 (53,300) 237 (53,300)
Stick Digging Force (SAE) – – 197 (44,300) 221 (49,700)
Heavy Duty – Power
Bucket Digging Force (ISO) 223 (50,100) 223 (50,100) – –
Stick Digging Force (ISO) 173 (38,900) 188 (42,300) – –
Bucket Digging Force (SAE) 205 (46,100) 205 (46,100) – –
Stick Digging Force (SAE) 170 (38,200) 184 (41,400) – –
Severe Duty
Bucket Digging Force (ISO) 223 (50,100) 223 (50,100) 259 (58,200) 259 (58,200)
Stick Digging Force (ISO) 173 (38,900) 188 (42,300) 202 (45,400) 227 (51,000)
Bucket Digging Force (SAE) 205 (46,100) 205 (46,100) 234 (52,600) 234 (52,600)
Stick Digging Force (SAE) 170 (38,200) 184 (41,400) 196 (44,100) 220 (49,500)
349E L Work Tool Offering Guide*
Boom Type Reach Boom (HD) Mass Boom
Stick Size R3.9 (HD) (12'10") R3.35 (HD) (11'0") M3.0 (9'10") M2.5 (8'2")
Hydraulic Hammer H160Ds H160Ds H160Ds H160Ds
H180Ds H180Ds H180Ds H180Ds
Multi­Processor MP30 MP30 MP30 MP30
Mobile Scrap and Demolition Shear S340B S340B S340B S340B
S365C** S365C** S365C** S365C**
S385C** S385C** S385C** S385C**
Contractors’ Grapple G330 G330 G330 G330
Trash Grapple
Thumbs
These work tools are available for the 349E.
Rippers
Consult your Cat dealer for proper match.
Center­Lock Pin Grabber Coupler
Dedicated Quick Coupler
*Matchesaredependentonexcavatorconfigurations.ConsultyourCatdealerforproperworktoolmatch.
**BoomMount
