Bucket and Stick Forces
HD Reach Boom
Mass Boom
6.9 m (22'8")
6.55 m (21'6")
Stick
R3.9TB
R3.35TB
M3.0UB
M2.5UB
(12'10")
(11'0")
(9'10")
(8'2")
kN (lbf)
kN (lbf)
kN (lbf)
kN (lbf)
General Duty
Bucket Digging Force (ISO)
268 (60,200)
268 (60,200)
296 (66,500)
296 (66,500)
Stick Digging Force (ISO)
184 (41,400)
201 (45,200)
212 (47,700)
241 (54,200)
Bucket Digging Force (SAE)
237 (53,300)
237 (53,300)
260 (58,500)
260 (58,500)
Stick Digging Force (SAE)
180 (40,500)
195 (43,800)
205 (46,100)
231 (51,900)
General Duty Capacity
Bucket Digging Force (ISO)
268 (60,200)
268 (60,200)
–
–
Stick Digging Force (ISO)
183 (41,100)
199 (44,700)
–
–
Bucket Digging Force (SAE)
239 (53,700)
239 (53,700)
–
–
Stick Digging Force (SAE)
178 (40,000)
193 (43,400)
–
–
Heavy Duty
Bucket Digging Force (ISO)
268 (60,200)
268 (60,200)
296 (66,500)
296 (66,500)
Stick Digging Force (ISO)
184 (41,400)
201 (45,200)
212 (47,700)
241 (54,200)
Bucket Digging Force (SAE)
237 (53,300)
237 (53,300)
260 (58,500)
260 (58,500)
Stick Digging Force (SAE)
180 (40,500)
195 (43,800)
205 (46,100)
231 (51,900)
Severe Duty
Bucket Digging Force (ISO)
268 (60,200)
268 (60,200)
292 (65,600)
292 (65,600)
Stick Digging Force (ISO)
184 (41,400)
201 (45,200)
211 (47,400)
240 (54,000)
Bucket Digging Force (SAE)
237 (53,300)
237 (53,300)
255 (57,300)
255 (57,300)
Stick Digging Force (SAE)
180 (40,500)
195 (43,800)
204 (45,900)
230 (51,700)
Extreme Duty
Bucket Digging Force (ISO)
262 (58,900)
262 (58,900)
–
–
Stick Digging Force (ISO)
183 (41,100)
199 (44,700)
–
–
Bucket Digging Force (SAE)
237 (53,300)
237 (53,300)
–
–
Stick Digging Force (SAE)
180 (40,500)
195 (43,800)
–
–
