349E L Hydraulic Excavator Specifications
349E L (LC-VG) HD Reach Boom Lift Capacities – Americas
LoadPointHeight LoadatMaximumReach LoadRadiusOverFront LoadRadiusOverSide
Boom–6.9m(22'8") Counterweight–9.0mt(9.9t) Bucket–None
Stick–R3.9TB(12'10") Shoes–900mm(35")triplegrouser
1.5 m/5.0 ft 3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft
m
ft
9.0m kg *7900 *7900 7.98
30.0 ft lb *17,550 *17,550 25.78
7.5m kg *7950 *7950 *7600 *7600 9.05
25.0 ft lb *16,750 *16,750 29.46
6.0m kg *11950 *11950 *11300 9300 *7550 *7550 9.77
20.0 ft lb *26,050 *26,050 *23,800 20,000 *16,600 *16,600 31.93
4.5m kg *15350 *15350 *13150 12000 *11900 9100 *7700 7400 10.22
15.0 ft lb *33,100 *33,100 *28,550 25,850 *25,900 19,550 *16,900 16,400 33.47
3.0m kg *24600 24350 *17850 15900 *14550 11500 *12650 8850 *8050 7050 10.43
10.0 ft lb *52,850 52,450 *38,600 34,300 *31,550 24,850 *27,450 19,000 *17,700 15,550 34.20
1.5m kg *25100 22900 *20000 15150 *15800 11100 12800 8550 *8650 6950 10.42
5.0 ft lb *59,550 49,350 *43,200 32,600 *34,250 23,900 27,550 18,450 *19,050 15,250 34.18
Ground
Line
kg *9700 *9700 *24100 22300 *21150 14650 16400 10750 12600 8350 *9600 7050 10.18
lb *22,000 *22,000 *55,700 47,900 *45,850 31,500 35,350 23,150 27,100 18,050 *21,200 15,550 33.40
–1.5m kg *16000 *16000 *28550 22100 *21300 14400 16200 10550 12450 8250 *11150 7500 9.71
–5.0 ft lb *36,000 *36,000 *61,900 47,500 *46,100 31,000 34,900 22,750 26,850 17,800 *24,650 16,500 31.82
–3.0m kg *23150 *23150 *26600 22200 *20300 14350 *16000 10550 12600 8350 8.96
–10.0 ft lb *52,250 *52,250 *57,600 47,700 *43,900 30,950 *34,500 22,700 27,850 18,500 29.29
–4.5m kg *30850 *30850 *23100 22500 *17900 14550 *13750 10700 *12750 10100 7.84
–15.0 ft lb *66,500 *66,500 *49,750 48,400 *38,400 31,350 *29,100 23,150 *28,100 22,550 25.52
–6.0m kg *17050 *17050 *12700 *12700 *12150 *12150 6.18
–20.0 ft lb *27,300 *27,300 19.45
Boom–6.9m(22'8") Counterweight–9.0mt(9.9t) Bucket–None
Stick–R3.35TB(11'0") Shoes–900mm(35")triplegrouser
1.5 m/5.0 ft 3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft
m
ft
9.0m kg *9000 *9000 7.44
30.0 ft lb *19,950 *19,950 23.95
7.5m kg *12150 *12150 *8500 *8500 8.57
25.0 ft lb *26,650 *26,650 *18,800 *18,800 27.88
6.0m kg *12800 12250 *11250 9200 *8400 *8400 9.33
20.0 ft lb *27,850 26,400 *21,650 19,700 *18,450 *18,450 30.48
4.5m kg *21500 *21500 *16450 *16450 *13900 11900 *12500 9000 *8500 7900 9.80
15.0 ft lb *46,100 *46,100 *35,550 *35,550 *30,200 25,600 *27,200 19,400 *18,750 17,400 32.09
3.0m kg *26500 23800 *18850 15700 *15200 11450 13050 8800 *8900 7500 10.02
10.0 ft lb *56,850 51,350 *40,700 33,900 *32,950 24,650 28,050 18,900 *19,550 16,450 32.85
1.5m kg *18550 *18550 *20700 15050 *16300 11050 12800 8550 *9550 7350 10.01
5.0 ft lb *44,150 *44,150 *44,700 32,400 *35,300 23,800 27,500 18,450 *21,000 16,200 32.83
Ground
Line
kg *21550 *21550 *21500 14650 16450 10750 12600 8400 *10600 7550 9.76
lb *49,900 48,000 *46,500 31,550 35,350 23,200 27,150 18,100 *23,350 16,600 32.02
–1.5m kg *15800 *15800 *27900 22300 *21200 14500 16300 10650 12550 8350 12050 8050 9.27
–5.0 ft lb *35,600 *35,600 *60,600 47,900 *45,900 31,200 35,050 22,950 27,050 18,050 26,650 17,750 30.36
–3.0m kg *24850 *24850 *25450 22450 *19750 14550 *15500 10700 *13000 9150 8.47
–10.0 ft lb *56,150 *56,150 *55,100 48,300 *42,650 31,300 *33,350 23,050 *28,650 20,200 27.70
–4.5m kg *27100 *27100 *21250 *21250 *16600 14800 *12750 11400 7.29
–15.0 ft lb *58,450 *58,450 *45,700 *45,700 *35,450 31,900 *28,000 25,400 23.68
*Indicatesthattheloadislimitedbyhydraulicliftingcapacityratherthantippingload.Theaboveloadsareincompliancewithhydraulicexcavatorliftcapacity
standardISO10567:2007.Theydonotexceed87%ofhydraulicliftingcapacityor75%oftippingload.Weightofallliftingaccessoriesmustbedeductedfromthe
aboveliftingcapacities.Liftingcapacitiesarebasedonthemachinestandingonafirm,uniformsupportingsurface.Theuseofaworktoolattachmentpointto
handle/liftobjects,couldaffectthemachineliftperformance.
AlwaysrefertotheappropriateOperationandMaintenanceManualforspecificproductinformation.
