349E L Hydraulic Excavator Specifications
Operating Weight and Ground Pressure
900 mm (36") 750 mm (30") 600 mm (24")
Triple Grouser Shoes Triple Grouser Shoes Double Grouser Shoes
kg (lb) kPa (psi) kg (lb) kPa (psi) kg (lb) kPa (psi)
Long FIX Undercarriage
HD Reach Boom – 6.9 m (22'8")
R3.9TB HD (12'10") 49 500 (109,100) 57.0 (8.3) 48 800 (107,600) 68.0 (9.9) 48 100 (106,000) 83.0 (12.0)
R3.35TB HD (11'0") 49 200 (108,500) 57.0 (8.3) 48 500 (106,900) 67.0 (9.7) 47 800 (105,400) 83.0 (12.0)
Mass Boom – 6.55 m (21'6")
M3.0UB HD (9'10") 50 500 (111,300) 58.0 (8.4) 49 700 (109,600) 69.0 (10.0) 49 100 (108,200) 85.0 (12.3)
M2.5UB HD (8'2") 50 200 (110,700) 58.0 (8.4) 49 500 (109,100) 69.0 (10.0) 48 800 (107,600) 85.0 (12.3)
Long VG Undercarriage
HD Reach Boom – 6.9 m (22'8")
R3.9TB HD (12'10") 52 200 (115,100) 61.0 (8.8) 51 500 (113,500) 72.0 (10.4) 50 700 (111,800) 88.0 (12.8)
R3.35TB HD (11'0") 52 000 (114,600) 60.0 (8.7) 51 200 (112,900) 71.0 (10.3) 50 500 (111,300) 88.0 (12.8)
Mass Boom – 6.55 m (21'6")
M3.0UB HD (9'10") 53 300 (117,500) 62.0 (9.0) 52,500 (115,700) 73.0 (10.6) 51 800 (114,200) 90.0 (13.1)
M2.5UB HD (8'2") 53 000 (116,800) 62.0 (9.0) 52,300 (115,300) 73.0 (10.6) 51 500 (113,500) 90.0 (13.1)
Major Component Weights*
kg lb
Base machine (with boom cylinder, without counterweight, front linkage and track)
Long FIX Undercarriage 24 200 53,400
Long VG Undercarriage 26 800 59,100
Counterweight
9.0 mt (9.9 t) 9000 19,800
Boom (includes lines, pins and stick cylinder)
Reach Boom – 6.9 m (22'8") 4510 9,900
Mass Boom – 6.55 m (21'6") 4750 10,500
Stick (includes lines, pins and bucket cylinder)
R3.9TB HD (12'10") 2750 6,100
R3.35TB HD (11'0") 2480 5,500
M3.0UB (9'10") 2930 6,500
M2.5UB (8'2") 2700 6,000
Track shoe (Long FIX/per two tracks)
600 mm (24") double grouser 5240 11,560
750 mm (30") triple grouser 5880 12,960
900 mm (36") triple grouser 6640 14,640
Track shoe (Long VG/per two tracks)
600 mm (24") double grouser 5300 11,680
750 mm (30") triple grouser 5940 13,100
900 mm (36") triple grouser 6700 14,780
Buckets
TB1880GD – 3.10 m 3 (4.05 yd 3 ) 2440 5,400
TB1555EX – 1.9 m 3 (2.49 yd 3 ) 2340 5,200
20
*Basemachineincludes75kg(165lb)operatorweight,90%fuelweight,andundercarriagewithcenterguard.
