Milton CAT C15 Factory Integral Fuel Tank Base - Manual (Page 3)

A T T A C H M E N T S
LEHE5511-00
3
Tank Only Tank and Package
Weight Height ‘A’ Length ‘B’
Open Enc.
PGS Height PGS Height
Liter Gallon Type kg lb mm in mm in mm in mm in
950 247 Integral 1021 2251 350 13.8 5800 228.3 NA NA 2350 92.5
1900 494 Integral 1283 2829 560 22.0 5800 228.3 NA NA 2560 100.8
Single Wall Integral – Width 1600 mm (63.0 in) Larne 60 Hz
Sound Attenuated Enclosure
Tank Only Tank and Package
Weight Height ‘A’ Length ‘B’
Open Enc.
PGS Height PGS Height
Liter Gallon Type kg lb mm in mm in mm in mm in
975 258 Integral 1016 2240 425 16.7 4250 167.3 2166 85.3 2425 95.5
1505 397 Integral 1241 2736 596 23.5 4250 167.3 2337 92.0 2596 102.2
Dual Wall Integral – Width 1600 mm (63.0 in) Larne
Weather Protective Attenuated Enclosure
Tank Only Tank and Package
Weight Height ‘A’ Length ‘B’
Open Enc.
PGS Height PGS Height
Liter Gallon Type kg lb mm in mm in mm in mm in
975 258 Integral 1185 2612 425 16.7 5220 205.5 NA NA 2425 95.5
1505 397 Integral 1436 3166 596 23.5 5220 205.5 NA NA 2596 102.2
Dual Wall Integral – Width 1600 mm (63.0 in) Larne 50 Hz
Sound Attenuated Enclosure
Tank Only Tank and Package
Weight Height ‘A’ Length ‘B’
Open Enc.
PGS Height PGS Height
Liter Gallon Type kg lb mm in mm in mm in mm in
975 258 Integral 1260 2778 425 16.7 5800 228.3 NA NA 2425 95.5
1505 397 Integral 1522 3355 596 23.5 5800 228.3 NA NA 2596 102.2
Dual Wall Integral – Width 1600 mm (63.0 in) Larne 60 Hz
Sound Attenuated Enclosure
