STANDBY 500 ekW 625 kVA
60 Hz 1800 rpm 480 Volts
TECHNICAL DATA
Open Generator Set - - 1800 rpm/60 Hz/480 Volts DM8155
Tier 2 and Low Emissions
Generator Set Package Performance
Genset Power rating @ 0.8 pf
Genset Power rating with fan 625 kVA
500 ekW
Fuel Consumption
100% load with fan
75% load with fan
50% load with fan 138.5 L/hr 36.6 Gal/hr
106.1 L/hr 28.0 Gal/hr
88.1 L/hr 23.3 Gal/hr
Cooling System
1
Air flow restriction (system)
Air flow (max @ rated speed for radiator arrangement)
Engine Coolant capacity with radiator/exp. tank
Engine coolant capacity
Radiator coolant capacity 0.12 kPa 0.48 in. water
822 m³/min 29029 cfm
57.8 L 15.3 gal
20.8 L 5.5 gal
37.0 L 9.8 gal
Inlet Air
Combustion air inlet flow rate 39.5 m³/min 1394.9 cfm
Exhaust System
Exhaust stack gas temperature
Exhaust gas flow rate
Exhaust flange size (internal diameter)
Exhaust system backpressure (maximum allowable) 505.6 º C 942.1 º F
108.8 m³/min 3842.2 cfm
152.4 mm 6.0 in
6.8 kPa 27.3 in. water
Heat Rejection
Heat rejection to coolant (total)
Heat rejection to exhaust (total)
Heat rejection to atmosphere from engine
Heat rejection to atmosphere from generator 189 kW 10748 Btu/min
486 kW 27639 Btu/min
119 kW 6768 Btu/min
29.1 kW 1654.9 Btu/min
Alternator
2
Motor starting capability @ 30% voltage dip
Frame
Temperature Rise 1428 skVA
LC6114F
130 º C
234 º F
Emissions (Nominal)
3
NOx g/hp-hr
CO g/hp-hr
HC g/hp-hr
PM g/hp-hr 5.74 g/hp-hr
.4 g/hp-hr
.01 g/hp-hr
.018 g/hp-hr
1
For ambient and altitude capabilities consult your Caterpillar dealer. Air flow restriction (system) is added to existing restriction from
factory.
2
Generator temperature rise is based on a 40º C (104º F) ambient per NEMA MG1-32.
3
Emissions data measurement procedures are consistent with those described in EPA CFR 40 Part 89, Subpart D & E and ISO8178-1 for
measuring HC, CO, PM, NOx. Data shown is based on steady state operating conditions of 77ºF, 28.42 in HG and number 2 diesel fuel
with 35º API and LHV of 18,390 btu/lb. The nominal emissions data shown is subject to instrumentation, measurement, facility and engine
to engine variations. Emissions data is based on 100% load and thus cannot be used to compare to EPA regulations which use values
based on a weighted cycle.
May 04 2009 13:45 PM 4
