390D L Hydraulic Excavator Specifi cations
390D L Mass Boom Lift Capacities – Americas
Load Point Height Load at Maximum Reach Load Radius Over Front Load Radius Over Side
Boom – 7.25 m (23 ft 9 in) Coupler – N/A Bucket – None
Stick – M3.4 m (11 ft 2 in) Shoes – 900 mm (36 in) double grouser
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft
m
ft
10.5 m kg *17 400 *17 400 6.96
35.0 ft lb *38,850 *38,850 22.17
9.0 m kg *21 650 *21 650 *15 900 *15 900 8.36
30.0 ft lb *45,800 *45,800 *35,300 *35,300 27.07
7.5 m kg *23 500 *23 500 *18 950 *18 950 *15 350 *15 350 9.32
25.0 ft lb *51,150 *51,150 *37,100 *37,100 *33,850 *33,850 30.36
6.0 m kg *29 350 *29 350 *24 900 *24 900 *22 200 18 900 *15 250 *15 250 9.95
20.0 ft lb *63,350 *63,350 *54,050 *54,050 *48,350 40,600 *33,600 *33,600 32.55
4.5 m kg *45 600 *45 600 *33 050 *33 050 *26 800 24 350 *23 000 18 350 *15 600 14 700 10.33
15.0 ft lb *97,750 *97,750 *71,300 *71,300 *58,000 52,450 *50,000 39,500 *34,300 32,500 33.84
3.0 m kg *36 200 32 500 *28 500 23 300 *23 850 17 800 *16 350 14 100 10.47
10.0 ft lb *78,250 70,000 *61,700 50,250 *51,700 38,300 *35,900 31,100 34.36
1.5 m kg *37 700 31 150 *29 500 22 500 *24 250 17 300 *17 600 14 050 10.40
5.0 ft lb *81,550 67,100 *63,850 48,450 *52,500 37,250 *38,650 30,900 34.12
Ground
Line
kg *27 950 *27 950 *37 150 30 500 *29 300 22 000 *23 800 17 000 *19 550 14 500 10.10
lb *64,650 *64,650 *80,500 65,650 *63,500 47,350 *51,450 36,550 *43,100 31,900 33.12
–1.5 m kg *23 550 *23 550 *41 700 *41 700 *34 700 30 350 *27 650 21 800 *22 000 16 900 *19 800 15 650 9.55
–5.0 ft lb *53,150 *53,150 *94,900 *94,900 *75,200 65,250 *59,800 46,900 *47,200 36,450 *43,650 34,500 31.28
–3.0 m kg *38 700 *38 700 *37 000 *37 000 *30 150 *30 150 *24 000 21 950 *18 800 17 950 8.70
–10.0 ft lb *87,400 *87,400 *80,250 *80,250 *65,150 *65,150 *51,450 47,300 *41,300 39,750 28.44
–4.5 m kg *27 250 *27 250 *22 550 *22 550 *16 350 *16 350 7.46
–15.0 ft lb *58,400 *58,400 *47,850 *47,850 *35,550 *35,550 24.23
Boom – 7.25 m (23 ft 9 in) Coupler – N/A Bucket – None
Stick – M2.92 m (9 ft 7 in) Shoes – 900 mm (36 in) double grouser
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft
m
ft
10.5 m kg *20 950 *20 950 6.27
9.0 m kg *22 600 *22 600 *18 950 *18 950 7.81
30.0 ft lb *44,200 *44,200 *42,050 *42,050 25.22
7.5 m kg *24 400 *24 400 *18 200 *18 200 8.82
25.0 ft lb *53,250 *53,250 *40,150 *40,150 28.73
6.0 m kg *39 800 *39 800 *30 550 *30 550 *25 700 24 950 *22 750 18 550 *18 100 16 950 9.49
20.0 ft lb *85,300 *85,300 *66,000 *66,000 *55,750 53,700 *49,650 39,850 *39,850 37,550 31.03
4.5 m kg *34 100 33 650 *27 400 23 950 *23 400 18 050 *18 550 15 550 9.89
15.0 ft lb *73,500 72,550 *59,300 51,550 *50,850 38,900 *40,800 34,350 32.39
3.0 m kg *36 800 31 850 *28 850 22 950 *24 000 17 550 *19 500 14 850 10.04
10.0 ft lb *79,450 68,650 *62,400 49,450 *52,100 37,750 *42,900 32,800 32.93
1.5 m kg *37 550 30 750 *29 450 22 200 *24 150 17 100 *21 150 14 800 9.96
5.0 ft lb *81,400 66,200 *63,800 47,850 *52,250 36,850 *46,500 32,600 32.68
Ground
Line
kg *25 950 *25 950 *36 300 30 250 *28 850 21 800 *23 300 16 850 *20 950 15 350 9.64
lb *60,500 *60,500 *78,850 65,100 *62,500 46,950 *50,250 36,350 *46,200 33,800 31.64
–1.5 m kg *40 350 *40 350 *33 250 30 250 *26 650 21 700 *20 650 16 900 *20 300 16 750 9.07
–5.0 ft lb *54,600 *54,600 *88,100 *88,100 *72,100 65,000 *57,600 46,750 *44,750 36,950 29.70
–3.0 m kg *33 300 *33 300 *27 950 *27 950 *22 050 22 000 *18 850 *18 850 8.17
–10.0 ft lb *72,350 *72,350 *60,350 *60,350 *46,950 *46,950 *41,400 *41,400 26.69
–4.5 m kg *18 900 *18 900 *15 600 *15 600 6.77
–15.0 ft lb *39,550 *39,550 *36,200 *36,200 21.22
Indicates that the load is limited by hydraulic lifting capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity *
standard ISO 10567:2007. They do not exceed 87% of hydraulic lifting capacity or 75% of tipping load. Weight of all lifting accessories must be deducted from the
above lifting capacities. Lifting capacities are based on the machine standing on a firm, uniform supporting surface.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
