390D L Hydraulic Excavator Specifi cations
390D L General Boom Lift Capacities – Americas
Load Point Height Load at Maximum Reach Load Radius Over Front Load Radius Over Side
Boom – 8.4 m (27 ft 7 in) Coupler – N/A Bucket – None
Stick – R4.4 m (14 ft 5 in) Shoes – 900 mm (36 in) double grouser
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft 12.0 m/40.0 ft
m
ft
10.5 m kg *15 350 *15 350 *11 350 *11 350 9.79
35.0 ft lb *31,700 *31,700 *25,200 *25,200 31.65
9.0 m kg *17 350 *17 350 *13 350 *13 350 *10 900 *10 900 10.82
30.0 ft lb *37,950 *37,950 *25,400 *25,400 *24,050 *24,050 35.23
7.5 m kg *18 050 *18 050 *16 900 15 300 *10 700 *10 700 11.57
25.0 ft lb *39,350 *39,350 *35,650 32,900 *23,600 *23,600 37.80
6.0 m kg *21 900 *21 900 *19 250 19 200 *17 500 14 950 *11 750 *11 750 *10 750 *10 750 12.09
20.0 ft lb *47,350 *47,350 *41,800 41,300 *38,100 32,200 *23,700 *23,700 39.57
4.5 m kg *30 450 *30 450 *24 300 24 250 *20 650 18 450 *18 250 14 550 *15 150 11 700 *11 050 *11 050 12.40
15.0 ft lb *65,550 *65,550 *52,450 52,300 *44,750 39,700 *39,700 31,250 *29,200 25,100 *24,250 *24,250 40.64
3.0 m kg *34 200 31 750 *26 500 23 000 *22 000 17 650 *19 050 14 050 *16 950 11 450 *11 500 10 700 12.52
10.0 ft lb *73,750 68,550 *57,300 49,650 *47,650 38,100 *41,350 30,250 *34,000 24,550 *25,300 23,550 41.07
1.5 m kg *36 300 30 250 *28 100 22 000 *23 050 17 000 *19 650 13 650 16 750 11 200 *12 200 10 600 12.46
5.0 ft lb *78,500 65,250 *60,750 47,450 *49,850 36,700 *42,600 29,350 *35,250 24,100 *26,850 23,300 40.87
Ground
Line
kg *36 650 29 500 *28 750 21 350 *23 500 16 550 *19 850 13 300 16 550 11 050 *13 300 10 750 12.21
lb *79,450 63,500 *62,250 46,000 *50,950 35,650 *43,000 28,700 *29,800 23,750 *29,250 23,700 40.05
–1.5 m kg *24 000 *24 000 *35 650 29 200 *28 400 21 000 *23 300 16 250 *19 500 13 150 *14 850 11 300 11.76
–5.0 ft lb *54,600 *54,600 *77,300 62,800 *61,550 45,250 *50,450 35,050 *42,050 28,300 *32,800 24,900 38.54
–3.0 m kg *23 450 *23 450 *33 350 *33 350 *33 350 29 250 *27 000 20 950 *22 200 16 200 *18 150 13 150 *16 500 12 250 11.09
–10.0 ft lb *52,700 *52,700 *75,900 *75,900 *72,300 62,900 *58,400 45,100 *47,850 34,900 *38,900 28,350 *36,350 27,100 36.29
–4.5 m kg *33 050 *33 050 *36 400 *36 400 *29 700 29 600 *24 300 21 150 *19 700 16 350 *16 150 14 000 10.15
–15.0 ft lb *74,550 *74,550 *78,800 *78,800 *64,150 63,650 *52,300 45,550 *42,150 35,350 *35,500 31,100 33.11
–6.0 m kg *28 900 *28 900 *24 100 *24 100 *19 550 *19 550 *15 050 *15 050 8.85
–20.0 ft lb *61,900 *61,900 *51,450 *51,450 *41,400 *41,400 *32,900 *32,900 28.71
Indicates that the load is limited by hydraulic lifting capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity *
standard ISO 10567:2007. They do not exceed 87% of hydraulic lifting capacity or 75% of tipping load. Weight of all lifting accessories must be deducted from the
above lifting capacities. Lifting capacities are based on the machine standing on a firm, uniform supporting surface.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
