21
390D L General Boom Lift Capacities – Americas
Load Point Height Load at Maximum Reach Load Radius Over Front Load Radius Over Side
Boom – 8.4 m (27 ft 7 in) Coupler – N/A Bucket – None
Stick – R5.5 m (18 ft 1 in) Shoes – 900 mm (36 in) double grouser
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft 12.0 m/40.0 ft 13.5 m/45.0 ft
m
ft
12.0 m kg *9050 *9050 9.83
40.0 ft lb *20,200 *20,200 31.62
10.5 m kg *10 950 *10 950 *8500 *8500 11.07
35.0 ft lb *21,900 *21,900 *18,800 *18,800 35.92
9.0 m kg *13 000 *13 000 *8200 *8200 12.00
30.0 ft lb *27,750 *27,750 *18,050 *18,050 39.10
7.5 m kg *14 450 *14 450 *11 500 *11 500 *8050 *8050 12.68
25.0 ft lb *31,150 *31,150 *23,250 *23,250 *17,750 *17,750 41.43
6.0 m kg *17 550 *17 550 *16 200 15 450 *13 500 12 350 *8100 *8100 13.15
20.0 ft lb *38,050 *38,050 *35,100 33,250 *28,200 26,450 *17,800 *17,800 43.05
4.5 m kg *27 100 *27 100 *22 200 *22 200 *19 200 19 050 *17 150 14 950 *15 400 12 050 *8250 *8250 13.43
15.0 ft lb *58,300 *58,300 *48,000 *48,000 *41,600 41,000 *37,300 32,150 *32,400 25,850 *18,150 *18,150 44.03
3.0 m kg *31 500 *31 500 *24 800 23 850 *20 800 18 200 *18 200 14 400 *16 300 11 700 *9000 *9000 *8600 *8600 13.54
10.0 ft lb *67,950 *67,950 *53,650 51,450 *45,100 39,250 *39,450 31,050 *35,450 25,150 *18,850 *18,850 44.43
1.5 m kg *34 800 31 350 *26 950 22 650 *22 200 17 450 *19 050 13 900 *16 800 11 400 *9050 *9050 13.48
5.0 ft lb *75,200 67,550 *58,300 48,850 *48,100 37,550 *41,350 29,950 36,400 24,450 *19,900 *19,900 44.25
Ground
Line
kg *19 000 *19 000 *36 450 30 100 *28 300 21 800 *23 150 16 850 *19 650 13 500 16 650 11 100 *9750 9600 13.25
lb *43,500 *43,500 *78,950 64,750 *61,300 46,900 *50,150 36,250 *42,550 29,050 35,800 23,900 *21,450 21,100 43.49
–1.5 m kg *14 250 *14 250 *23 200 *23 200 *36 600 29 450 *28 750 21 200 *23 500 16 400 *19 750 13 200 16 450 10 950 *10 700 9950 12.84
–5.0 ft lb *31,950 *31,950 *52,800 *52,800 *79,250 63,300 *62,200 45,700 *50,850 35,300 *42,750 28,450 35,400 23,550 *23,650 21,900 42.11
–3.0 m kg *20 200 *20 200 *29 400 *29 400 *35 350 29 200 *28 150 20 950 *23 050 16 200 *19 250 13 050 *15 550 10 900 *12 200 10 650 12.23
–10.0 ft lb *45,350 *45,350 *66,800 *66,800 *76,600 62,800 *60,900 45,100 *49,850 34,850 *41,500 28,150 *27,550 23,500 *26,950 23,450 40.06
–4.5 m kg *27 050 *27 050 *37 750 *37 750 *32 850 29 300 *26 400 20 950 *21 650 16 150 *17 700 13 100 *14 500 11 800 11.39
–15.0 ft lb *60,950 *60,950 *85,900 *85,900 *70,950 63,000 *57,000 45,100 *46,550 34,850 *37,750 28,250 *32,200 26,150 37.21
–6.0 m kg *35 550 *35 550 *35 950 *35 950 *28 700 *28 700 *23 250 21 200 *18 750 16 400 *14 900 13 850 10.26
–20.0 ft lb *80,450 *80,450 *77,350 *77,350 *61,650 *61,650 *49,750 45,700 *39,750 35,400 *32,650 30,850 33.37
–7.5 m kg *27 300 *27 300 *22 250 *22 250 *17 700 *17 700 *13 650 *13 650 8.71
–25.0 ft lb *57,700 *57,700 *46,900 *46,900 *36,800 *36,800 *29,750 *29,750 28.11
Indicates that the load is limited by hydraulic lifting capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity *
standard ISO 10567:2007. They do not exceed 87% of hydraulic lifting capacity or 75% of tipping load. Weight of all lifting accessories must be deducted from the
above lifting capacities. Lifting capacities are based on the machine standing on a firm, uniform supporting surface.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
