390D L Hydraulic Excavator Specifi cations
390D L Reach Boom Lift Capacities – Americas
Load Point Height Load at Maximum Reach Load Radius Over Front Load Radius Over Side
Boom – 10.0 m (32 ft 10 in) Coupler – N/A Bucket – None
Stick – R4.4 m (14 ft 5 in) Shoes – 900 mm (36 in) double grouser
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft 12.0 m/40.0 ft 13.5 m/45.0 ft
m
ft
12.0 m kg *12 950 *12 950 *12 950 *12 950 10.50
40.0 ft lb *28,750 *28,750 33.88
10.5 m kg *14 550 *14 550 *12 450 *12 450 11.67
35.0 ft lb *31,850 *31,850 *27,500 *27,500 37.92
9.0 m kg *14 850 *14 850 *13 950 12 000 *12 250 10 950 12.55
30.0 ft lb *32,300 *32,300 *30,500 25,600 *26,950 24,450 40.94
7.5 m kg *17 250 *17 250 *15 450 14 750 *14 150 11 750 *12 250 9800 13.20
25.0 ft lb *37,300 *37,300 *33,500 31,800 *30,850 25,200 *26,950 21,750 43.17
6.0 m kg *28 250 *28 250 *22 100 *22 100 *18 500 18 000 *16 200 14 150 *14 600 11 400 *13 450 9250 *12 450 9050 13.66
20.0 ft lb *60,550 *60,550 *47,550 *47,550 *40,050 38,850 *35,100 30,500 *31,700 24,450 *27,350 19,950 44.73
4.5 m kg *24 250 21 950 *19 850 17 000 *17 000 13 550 *15 050 11 000 *13 650 9000 *12 800 8500 13.93
15.0 ft lb *52,250 47,500 *42,850 36,650 *36,850 29,150 *32,700 23,600 29,450 19,300 *28,150 18,800 45.67
3.0 m kg *25 900 20 550 *20 950 16 050 *17 750 12 900 *15 500 10 600 13 450 8800 12 650 8200 14.04
10.0 ft lb *55,900 44,400 *45,300 34,700 *38,400 27,850 *33,600 22,800 28,950 18,850 27,850 18,100 46.05
1.5 m kg *26 700 19 600 *21 650 15 350 *18 250 12 400 15 750 10 250 13 250 8550 12 550 8100 13.98
5.0 ft lb *57,750 42,350 *46,850 33,150 *39,500 26,750 33,950 22,050 28,450 18,400 27,650 17,850 45.88
Ground
Line
kg *13 200 *13 200 *26 650 19 100 *21 850 14 900 *18 400 12 050 15 500 10 000 13 100 8400 12 750 8200 13.76
lb *31,400 *31,400 *57,700 41,200 *47,300 32,100 *39,850 25,950 33,350 21,500 28,150 18,100 28,050 18,000 45.14
–1.5 m kg *20 100 *20 100 *25 850 18 950 *21 500 14 650 *18 150 11 800 15 350 9850 13 200 8500 13.36
–5.0 ft lb *46,550 *46,550 *56,100 40,750 *46,550 31,500 *39,300 25,450 33,000 21,150 29,100 18,700 43.82
–3.0 m kg *17 950 *17 950 *28 350 26 800 *24 450 18 950 *20 600 14 550 *17 400 11 750 *14 700 9800 *13 200 9050 12.78
–10.0 ft lb *40,950 *40,950 *63,000 57,600 *53,050 40,800 *44,500 31,400 *37,550 25,350 *31,500 21,150 *29,100 20,000 41.85
–4.5 m kg *26 800 *26 800 *26 100 *26 100 *22 350 19 200 *18 950 14 700 *15 950 11 850 *12 950 10 000 11.98
–15.0 ft lb *60,950 *60,950 *56,700 *56,700 *48,350 41,300 *40,850 31,700 *34,200 25,600 *28,500 22,200 39.14
–6.0 m kg *24 850 *24 850 *22 350 *22 350 *19 350 *19 350 *16 400 15 050 *13 300 12 200 *12 350 11 650 10.90
–20.0 ft lb *53,750 *53,750 *48,150 *48,150 *41,600 *41,600 *35,000 32,450 *27,900 26,450 *27,000 26,000 35.51
–7.5 m kg *17 100 *17 100 *14 900 *14 900 *12 100 *12 100 *10 950 *10 950 9.47
–25.0 ft lb *36,250 *36,250 *31,400 *31,400 *24,800 *24,800 *23,700 *23,700 30.63
Indicates that the load is limited by hydraulic lifting capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity *
standard ISO 10567:2007. They do not exceed 87% of hydraulic lifting capacity or 75% of tipping load. Weight of all lifting accessories must be deducted from the
above lifting capacities. Lifting capacities are based on the machine standing on a firm, uniform supporting surface.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
