Page 16
16
390D L Hydraulic Excavator Specifi cations
Dimensions
All dimensions are approximate
Reach Boom
General Purpose Boom
Mass Boom
10.0 m (32'10")
8.4 m (27'7")
7.25 m (23'9")
Stick
R5.5 m
R4.4 m
R5.5 m
R4.4 m
GP3.7 m
GP3.4 m
GP2.92 m
M3.4 m
M2.92 m
(18'1")
(14'5")
(18'1")
(14'5")
(12'2")
(11'2")
(9'7")
(11'2")
(9'7")
Bucket
HB3.9 m
3
HB3.9 m
3
HB4.6 m
3
HB4.6 m
3
HB4.6 m
3
JC4.6 m
3
JC4.6 m
3
JC6.0 m
3
JC6.0 m
3
(5.1 yd
3
)
(5.1
yd
3
)
(6.0
yd
3
)
(6.0
yd
3
)
(6.0
yd
3
)
(6.0
yd
3
)
(6.0
yd
3
)
(7.8
yd
3
)
(7.8
yd
3
)
1 Shipping Height
mm
5430
5030
5840
5290
5010
5160
4970
5310
4900
ft
17.81
16.50
19.16
17.35
16.43
16.92
16.30
17.42
16.07
2 Shipping Length
mm
16 280
16 320
14 490
14 700
14 710
14 720
14 910
13 560
13 690
ft
53.41
53.54
47.53
48.22
46.48
48.29
48.91
44.48
44.91
3 Tail Swing Radius
mm
4680
4680
4680
4680
4680
4680
4680
4680
4680
ft
15.35
15.35
15.35
15.35
15.35
15.35
15.35
15.35
15.35
4 Length to Center
of Rollers***
mm
5120
5120
5120
5120
5120
5120
5120
5120
5120
ft
16.79
16.79
16.79
16.79
16.79
16.79
16.79
16.79
16.79
5 Track Length****
mm
6360
6360
6360
6360
6360
6360
6360
6360
6360
ft
20.86
20.86
20.86
20.86
20.86
20.86
20.86
20.86
20.86
6 Ground Clearance
mm
900
900
900
900
900
900
900
900
900
ft
2.95
2.95
2.95
2.95
2.95
2.95
2.95
2.95
2.95
7 Track Gauge (Shipping)*
mm
2750
2750
2750
2750
2750
2750
2750
2750
2750
ft
9.02
9.02
9.02
9.02
9.02
9.02
9.02
9.02
9.02
8 Transport Width**
mm
4260
4260
4260
4260
4260
4260
4260
4260
4260
ft
13.97
13.97
13.97
13.97
13.97
13.97
13.97
13.97
13.97
(LC)
(LC)
(LC)
(LC)
(LC)
(LC)
(LC)
(LC)
(LC)
9 Cab Height
mm
3760
3760
3760
3760
3760
3760
3760
3760
3760
ft
12.33
12.33
12.33
12.33
12.33
12.33
12.33
12.33
12.33
* Track gauge in extended (working) position: 3510 mm (11.51 ft).
** Transport width shown for 750 mm (30 in).
Add 150 mm (6 in) for 900 mm (36 in) shoes.
Subtract 100 mm (4 in) for 650 mm (26 in) shoes.
*** STD 4600 mm (15.09 ft) (STD), 5120 mm (16.79 ft) (LC).
**** STD 5840 mm (19.16 ft) (STD), 6360 mm (20.86 ft) (LC).
3
1
4
5
8
7
9
6
2
