24 336D L Hydraulic Excavator specifications
BOOM – 6.18 m (20'3")
STICK – 2.55 m (8'4") BUCKET – TB 36" HD
with General Duty Tips (x4)
1819.8 kg (4,012 lb)
SHOES – 800 mm (32") triple grouser
UNDERCARRIAGE – Long
HEAVY LIFT – On
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
Mass Boom Lift Capacities
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft
m m
ft ft
9.0 m kg *4220 *4220 7.32
30.0 ft lb *9,400 *9,400 23.47
7.5 m kg *5880 *5880 7.11 *3900 *3900 8.65
25.0 ft lb *13,050 *13,050 23.00 *8,600 *8,600 28.12
6.0 m kg *8030 *8030 *7460 5940 *5680 5060 8.06 *3810 3750 9.47
20.0 ft lb *17,450 *17,450 *16,350 12,650 *12,550 11,300 26.27 *8,400 8,350 30.93
4.5 m kg *11 540 *11 540 *9170 8710 *7930 5770 *5750 4260 8.64 *3860 3260 9.93
15.0 ft lb *24,800 *24,800 *19,850 18,700 *17,250 12,350 *12,650 9,450 28.29 *8,500 7,200 32.51
3.0 m kg *14 560 12 800 *10 600 8070 *8640 5480 *6070 3860 8.94 *4050 3030 10.09
10.0 ft lb *31,300 27,650 *22,900 17,400 *18,750 11,750 *13,350 8,500 29.32 *8,900 6,700 33.09
1.5 m kg *16 800 11 620 *11 870 7490 9080 5190 *6640 3710 8.98 *4390 3020 9.97
5.0 ft lb *36,250 25,050 *25,650 16,100 19,500 11,150 *14,600 8,200 29.46 *9,650 6,650 32.73
Ground kg *17 550 11 090 *12 570 7110 8840 4980 6850 3810 8.76 *4930 3240 9.57
Line lb *38,000 23,850 *27,200 15,300 19,000 10,700 15,100 8,400 28.73 *10,850 7,150 31.41
–1.5 m kg *15 590 *15 590 *17 070 11 020 *12 530 6970 8760 4900 7530 4210 8.26 *5800 3780 8.85
–5.0 ft lb *35,300 *35,300 *37,000 23,650 27,050 15,000 18,850 10,550 16,650 9,300 27.06 *12,800 8,350 28.99
–3.0 m kg *19 920 *19 920 *15 480 11 230 *11 510 7070 *8440 5110 7.42
–10.0 ft lb *44,150 *44,150 *33,450 24,150 *24,750 15,200 *18,600 11,350 24.25
–4.5 m kg *16 420 *16 420 *12 240 11 750 *8580 7480
–15.0 ft lb *35,200 *35,200 *26,100 25,300
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
Load at Maximum
Reach – Bucket Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤ Load at Maximum
Reach – Bucket Extended
