22 336D L Hydraulic Excavator specifications
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
Reach Boom Lift Capacities
BOOM – 6.5 m (21'4")
STICK – 3.9 m (12'10")
COUNTERWEIGHT – 6000 kg (13,228 lb) BUCKET – No Bucket,
Bare Coupler Only
556 kg (1,226 lb)
SHOES – 800 mm (32") triple grouser
UNDERCARRIAGE – LC-Fix
HEAVY LIFT – On
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) 9.0 m (30.0 ft)
m
ft
9.0 m kg *4770 *4770 7.88
30.0 ft lb *12,200 *12,200 24.84
7.5 m kg *4430 *4430 9.00
25.0 ft lb *9,800 *9,800 29.29
6.0 m kg *6510 5070 *4300 4280 9.77
20.0 ft lb *14,400 *14,400 *14,350 10,850 *9,500 *9,500 31.92
4.5 m kg *7310 6800 *6840 4940 *4330 3820 10.26
15.0 ft lb *15,900 14,600 *14,950 10,600 *9,500 8,450 33.59
3.0 m kg *12 770 *12 770 *9790 9180 *8250 6440 *7350 4740 *4430 3560 10.51
10.0 ft lb *27,500 *27,500 *21,200 19,800 *17,900 13,850 *16,050 10,200 *9,750 7,850 34.46
1.5 m kg *15 930 13 050 *11 480 8520 *9220 6080 7460 4540 *4690 3450 10.54
5.0 ft lb *34,350 28,150 *24,850 18,350 *20,000 13,100 16,050 9,750 *10,300 7,600 34.58
Ground kg *8110 *8110 *17 850 12 210 *12 750 8010 9630 5770 7270 4360 *5110 3480 10.35
Line lb *18,500 *18,500 *38,600 26,300 *27,600 17,250 20,700 12,450 15,650 9,400 *11,250 7,650 33.96
–1.5 m kg *7370 *7370 *11 620 *11 620 *18 460 11 840 13 330 7710 9410 5570 7150 4250 *5780 3670 9.93
–5.0 ft lb *16,450 *16,450 *26,250 *26,250 *40,000 25,450 28,650 16,600 20,250 12,000 15,400 9,150 *12,800 8,100 32.57
–3.0 m kg *11 590 *11 590 *16 410 *16 410 *17 990 11 780 13 210 7610 9330 5500 7140 4240 6870 4090 9.26
–10.0 ft lb *25,950 *25,950 *37,100 *37,100 *38,950 25,300 28,400 16,400 20,100 11,850 15,400 9,150 15,200 9,050 30.28
–4.5 m kg *16 550 *16 550 *23 010 *23 010 *16 420 11 940 *12 290 7690 *9370 5580 *7970 4920 8.25
–15.0 ft lb *37,200 *37,200 *50,500 *50,500 *35,400 25,700 *26,450 16,600 *20,000 12,050 *17,600 10,950 26.87
–6.0 m kg *18 350 *18 350 *13 250 12 360 *9720 8000 *7950 6790 6.77
–20.0 ft lb *39,050 *39,050 *28,200 26,650 *20,400 17,300 *17,600 15,400 21.81
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
Load at Maximum
Reach – Coupler Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
