23 336D L Hydraulic Excavator specifications
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
Reach Boom Lift Capacities
BOOM – 6.5 m (21'4")
STICK – 3.2 m (10'6")
COUNTERWEIGHT – 6000 kg (13,228 lb) BUCKET – No Bucket,
Bare Coupler Only
556 kg (1,226 lb)
SHOES – 800 mm (32") triple grouser
UNDERCARRIAGE – LC-Fix
HEAVY LIFT – On
* Limited by hydraulic capacity rather than tipping load. The above loads are in compliance with SAE hydraulic excavator lift capacity rating standard J1097.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. Weight of all lifting accessories must be deducted from the above
lifting capacities.
1.5 m (5.0 ft) 3.0 m (10.0 ft) 4.5 m (15.0 ft) 6.0 m (20.0 ft) 7.5 m (25.0 ft) 9.0 m (30.0 ft)
m
ft
9.0 m kg *6150 *5640 6.89
30.0 ft lb
7.5 m kg *7190 7030 *5690 *6150 8.15
25.0 ft lb *15,900 15,050
6.0 m kg *7410 6930 *5530 5690 8.99
20.0 ft lb *16,250 14,900 *12,200 11,050 29.35
4.5 m kg *9150 *9150 *8070 6680 *7480 4860 *5570 4950 9.52
15.0 ft lb *19,800 *19,800 *17,550 14,350 *16,400 10,400 *12,250 9,700 31.17
3.0 m kg *14 510 13 850 *10 780 8970 *8930 6350 7630 4710 *5790 4370 9.79
10.0 ft lb *31,200 29,900 *23,300 19,350 *19,400 13,700 16,400 10,100 *12,750 8,950 32.10
1.5 m kg *17 230 12 700 *12 280 8380 *9790 6030 7450 4540 *6190 4050 9.82
5.0 ft lb *37,150 27,400 *26,550 18,050 *21,250 13,000 16,000 9,750 13,650 8,650 32.23
Ground kg *7480 *7480 *18 480 12 110 *13 280 7970 9630 5780 7300 4400 6600 3920 9.62
Line lb *17,100 *17,100 *40,000 26,050 *28,750 17,200 20,700 12,450 15,700 9,450 14,550 8,750 31.57
–1.5 m kg *8720 *8720 *12 800 *12 800 *18 480 11 920 13 380 7770 9470 5640 7240 4350 7050 3970 9.17
–5.0 ft lb *19,450 *19,450 *28,950 *28,950 *40,050 25,650 28,750 16,750 20,400 12,150 15,600 9,350 15,550 9,350 30.06
–3.0 m kg *14 080 *14 080 *19 210 *19 210 *17 470 11 980 *13 100 7750 9470 5640 8010 4230 8.43
–10.0 ft lb *31,550 *31,550 *43,500 *43,500 *37,850 25,750 *28,300 16,700 20,400 12,150 *17,750 10,650 27.56
–4.5 m kg *20 930 *20 930 *15 260 12 250 *11 510 7920 *8740 7810 7.31
–15.0 ft lb *45,100 *45,100 *32,850 26,400 *24,650 17,100 *19,250 13,500 23.75
–6.0 m kg *10 940 *10 940 *8370 *8370 5.57
–20.0 ft lb *22,850 *22,850 *18,450 *18,450 17.74
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
Load at Maximum
Reach – Coupler Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
