11
Loader
Bucket Capacity
– General Purpose 0.76 m 3 1 yd 3
Bucket Width
– General Purpose 2262 mm 7 ft 5 in
Dump Height
@ Max Angle
– Single Tilt 2651 mm 8 ft 8 in
Dump Reach
@ Max Angle
– Single Tilt 772 mm 2 ft 6 in
Dig Depth
– Single Tilt 106 mm 4 in
Lift Capacity
@ Full Height
– Single Tilt 2803 kg 6,180 lb
Bucket Breakout
Force – Single Tilt 44.6 kN 10,036 lb
Hydraulic System
Circuit Type Closed center, load
sensing
Pump Capacity
(@ 2,200 rpm) 132 L/min 34.8 gal/min
System Pressure
– Backhoe 22 700 kPa 3,300 psi
System Pressure
– Loader 20 700 kPa 3,000 psi
Pump Type Variable-flow, axial
piston
Steering Type Front wheel
Power Steering Hydrostatic, HMU
2WD Cylinder
– Bore 65 mm 2.6 in
Stroke 120 mm 4.7 in
Rod Diameter 36 mm 1.4 in
4WD Cylinder
– Bore 65 mm 2.6 in
Stroke 120 mm 4.7 in
Rod Diameter 36 mm 1.4 in
Brake System Inboard, oil-immersed,
multiple disc
Power Train
Power-Shuttle,
Forward 1st 6 km/h 3.7 mph
Forward 2nd 9.6 km/h 5.9 mph
Forward 3rd 20 km/h 12 mph
Forward 4th 40 km/h 25 mph
Power-Shuttle,
Reverse 1st 6 km/h 3.7 mph
Reverse 2nd 9.6 km/h 5.9 mph
Reverse 3rd 20 km/h 12 mph
Reverse 4th 40 km/h 25 mph
Conveniently placed, hand operated lever •
provides instant direction changes between
forward and reverse through power hydraulic
clutches.
Torque converter free-wheel clutch allows
•
the converter stator to free-wheel during
high speed, low torque conditions such
as roading.
Single-stage, 2.63:1 stall ratio.
•
Travel speeds of two wheel drive backhoe •
loader at full throttle when equipped with
19.5 × 24 rear tires.
Operating Specifications
– Backhoe
Turning Circle:
outside, front wheels 8.18 m 26 ft 10 in
Turning Circle:
outside, widest
loading bucket 10.97 m 36 ft
ISO 5010. •
2WD, 4WD (inner wheel not braked). •
Service Refills
Cooling System 20.5 L 5.4 gal
Fuel Tank 170 L 45 gal
Engine Oil w/Filter 7.6 L 2 gal
Transmission-Torque
Converter, 2WD,
Power Shuttle 18.5 L 4.9 gal
Transmission-Torque
Converter, 4WD,
Power Shuttle 18.5 L 4.9 gal
Rear Axle 16.5 L 4.4 gal
Rear Axle,
Planetaries 1.7 L 0.4 gal
Front Axle, 4WD 11 L 2.9 gal
Front Axle,
Planetaries 0.7 L 0.2 gal
Hydraulic System 90 L 23.8 gal
Hydraulic Tank 38 L 10 gal
Standards
Brakes SAE J/ISO 3450, ISO
3450 1996
Cab – ROPS SAE J1040 May 1994/
ISO 3741 1994
Cab – FOPS SAE J/ISO 3449
APR98 LEVEL II
and ISO 3449: 1992
LEVEL II
Cab – Sound ANSI/SAE J1166
Oct 98 is 80 dB (A)
Exterior Sound SAE J88 JUN86 is
76 dB (A)
