Cortech GW CREASEMASTER PLUS 4600 CREASING SYSTEM User Manual
Page 51
Page 51
94-072-GW
X
X
Pneumatic Drive Unit
94-073-GW
X
X
Complete Pneumatic Drive Unit w/Reverse #ring Head
94-083-GW
X
X
LV Solenoid to MSTP Board Power Cable
94-084-GW
X
X
Drive Unit Connection Metal Plate
96-009-GW
X
X
Register Board
96-012-GW
X
X
Register Guide
96-015-GW
X
X
Register Board Ball Holder
96-017-GW
X
X
Register Board Cross Shaft Supports
96-018-GW
X
X
Register Board Bearing Blocks
96-023-GW
X
X
Register Board Conveyor Spool
96-024-GW
X
X
Non-Operator Side Stock Guide
96-035-GW
X
X
X
Double Stand
96-070-GW
X
X
LV Solenoid Connection: Phone Jack to Solenoid
96-071-GW
X
X
LV Solenoid Connection: Board to Phone Jack Connector
98-001-GW
X
X
FM Non-Operator Side Plate
98-002-GW
X
X
FM Operator Side Plate
98-003-GW
X
X
Small Side Cover
98-006-GW
X
X
Display Label
98-006S-GW
X
X
Operator Side Cover Strip
98-007-GW
X
X
Red - Alternate Push Button Switch
98-071-GW
X
X
Large Red -Alternate Push Button
98-009-GW
X
X
Metal Display Panel
98-200-GW
OP
OP
Strike perf assembly c/w solenoid, regulator, hose, cable, & bracket
98-200-CM
OP
Strike perf assembly c/w solenoid, regulator, hose, cable, & bracket
98-201-GW
OP
OP
OP
Strike perf accessory holder w/ 12 tpi perf blade
98-202-GW
OP
OP
OP
Strike perf "y" union & hose
98-203-GW
OP
OP
OP
Strike perf pneumatic cylinder
98-204-GW
OP
OP
Strike perf solenoid w/ cable 12v
98-204-CM
OP
Strike perf solenoid w/ cable 24v
98-205-GW
OP
OP
OP
6mm hose per 6" length
98-207-GW
OP
OP
OP
Strike perf mini regulator
98-208-GW
OP
OP
OP
regulator fitting
98-209-GW
OP
OP
OP
bracket
98-210-GW
OP
OP
strike perf 4 pin connector
100-001-GW
X
X
Connector Board SN 2111 AND HIGHER
100-002-GW
X X X X
X
Controller Board SN 2111 AND HIGHER
100-003-GW
X X X X
X
KeyPad SN 2111 AND HIGHER
CBS 100XL037
X
X
Timing Belt ( Air Feed )
CBS 140XL037
X
X
Timing Belt
CBS 170XL037
X
X
X
Timing Belt
CBS 12XL037
X
X
Pulley
CM-0001
X
X
X
Upper Die Male
CM-0001 N
X
X
X
Upper Die Male - Narrow
CM-0002
X
X
X
Upper Die Female
CM-0002 N
X
X
X
Upper Die Female Narrow
CM-0003
X
X
X
Bottom Die
CM-0003N
X
X
X
Bottom Die Narrow
CM-0003LC
X
X
X
Bottom Die Combination Narrow / Wide
CM-0003S
X
X
X
Botom Die Spring
