Cortech GW CREASEMASTER PLUS 4600 CREASING SYSTEM - Manual

Page 1
CreaseMaster Plus TS - Reference Manual
Table of Contents
1.0 General
Operation
1.1 Technical Data
1.2 Safety Regulations
1.3
Cautions Concerning Machine
2.0 Machine Assembly
2.1 Power Supply Instructions
2.2 Air Regulator Instructions
3.0 Getting Ready
3.1 Paper Gate Adjustments
3.2 Self Centering Air Feed
3.3 Optional Conveyor Out Feed
4.0
Setting Up a Job
4.1 Operating the Touch Screen
5.0
Idler Wheels/Perforating/Slitting
5.1 Idler Wheels
5.2 Perforating/Slitting
6.0 Cleaning
& Maintenance
6.1 Cleaning
6.2 Maintenance
Diagrams and Parts Listing
