20ETF..SPbF Soft Recovery Series
Vishay High Power Products Surface Mountable Fast
Soft Recovery Rectifier Diode, 20 A
ORDERING INFORMATION TABLE
1 - Current rating (20 = 20 A)
2 - Circuit configuration:
E = Single diode
3 - Package:
T = D 2 PAK (TO-220AC)
4 - Type of silicon:
F = Fast soft recovery rectifier
5 - Voltage code x 100 = V
RRM
6 - S = Surface mountable
7 - None = Tube
TRR = Tape and reel (right oriented)
TRL = Tape and reel (left oriented)
8 - None = Standard production
PbF = Lead (Pb)-free
02 = 200 V
04 = 400 V
06 = 600 V
Device code
5 1 3 2 4 6 7 8
20 E T F 06 S TRL PbF
LINKS TO RELATED DOCUMENTS
Dimensions http://www.vishay.com/doc?95046
Part marking information http://www.vishay.com/doc?95008
Packaging information http://www.vishay.com/doc?95032
