Altronix AL600UL3X Installation Instructions User Manual
Page 3
Maintenance:
Unit should be tested at least once a year for the proper operation as follows:
Output Voltage Test: Under normal load conditions, the DC output voltage should be checked for proper voltage level
(see power supply output specifications table).
Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage at
the battery terminals and at the board terminals marked [- BAT +] to insure that there is no break in the battery
connection wires.
Note: Maximum charge current under discharge is 0.7 amp.
Note: Expected battery life is 5 years, however it is recommended changing batteries in 4 years or less if necessary.
LED Diagnostics:
AL600ULXB - Power Supply
LED
Red (DC)
Green (AC)
Power Supply Status
ON
ON
Normal operating condition.
ON
OFF
Loss of AC, Stand-by battery supplying power.
OFF
ON
No DC output. Short circuit or thermal overload condition.
OFF
OFF
No DC output. Loss of AC. Discharged battery.
Terminal Identification:
AL600ULXB - Power Supply
Terminal
Function/Description
Legend
L, G, N
Connect 115VAC to these terminals: L to hot, N to neutral, G to ground.
+ DC -
24VDC @ 6 amp continuous non-power limited output. Supplies power to AL3XB.
AC FAIL
Used to notify loss of AC power, e.g. connect to audible device or alarm panel. Relay
C, N.C., N.O.
normally energized when AC power is present. Contact rating 1 amp @ 28VDC.
AC or brownout fail is reported within 1 minute of event. To delay reporting of up to
6 hrs., cut “AC delay” jumper and reset power to unit.
BAT FAIL
Used to indicate low battery condition, e.g. connect to alarm panel. Relay normally
N.O., N.C., C
energized when DC power is present. Contact rating 1 amp @ 28VDC.
A removed battery is reported within 5 minutes. Battery reconnection is reported
within 1 minute.
Low battery threshold is set @ approximately 21VDC.
- BAT +
Stand-by battery connections. Maximum charge rate .7 amp.
AL3XB - Power Output Module
Terminal Legend
Function/Description
- INPUT +
24VDC from power supply (AL600ULXB).
- OUT 1 +
24VDC @ 3 amp continuous power limited output.
- OUT 2 +
12VDC @ 1.75 amp continuous power limited output.
- OUT 3 +
5VDC @ 1.75 amp continuous power limited output.
3
