- 2 - AL842ULADA
Agency Listings:
• UL Listed for Control Units for Fire Protective
Signaling Systems (UL 864).
• MEA - NYC Department of Buildings Approved.
• CSFM - California State Fire Marshal Approved.
• FM - Factory Mutual Approved.
• NFPA 72 Compliant.
Input:
• Power input 120VAC / 60 Hz, 5 amp.
• Two (2) Class A, Style Z or two (2) Class B,
Style W, Y FACP inputs.
• Two (2) NC dry contact trigger inputs.
Output:
• Class 2 Rated power limited outputs.
• 24VDC voltage regulated power limited outputs.
• 8 amp max total alarm current.
• 2.5A max current per output.
• Two auxiliary outputs rated at 1 amp each
(1 amp continuous, 1 amp AC disconnect).
• Programmable supervised indicating circuit outputs:
Four (4) Class B, Style W, Y or Four (4) Class A,
Style Z or Two (2) Class A, Style Z and Two (2) Class B,
Style W, Y (see Application Guide).
• Thermal and short circuit protection with auto reset.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switchover to stand-by battery when
AC fails.
• Zero voltage drop when switching over to
battery backup.
Supervision:
• AC fail supervision (form “C” contact, 1 amp / 28VDC).
Factory set for 30 seconds with optional 2.5 to 3 hour
delay setting (field selectable).
• Instant local AC trouble reporting relay
(form “C” contact, 1 amp / 28VDC).
• Battery presence and low battery supervision
(form “C” contact, 1 amp / 28VDC).
Visual Indicators:
• Input and output status LED indicators.
Special Features:
• 2-wire horn/strobe Sync mode allows audible
notification appliances (horns) to be silenced
while visual notification appliances (strobes)
continue to operate.
• Sync protocols include Potter/Amseco, Faraday,
Gentex ® , System Sensor ® , and CooperWheelock ® .
• Temporal Code 3, Steady Mode, Input to Output
Follower Mode (maintains synchronization of
notification appliances circuit).
• Compatible with 12VDC or 24VDC fire panels.
• Output loop supervision directed to input 1 or input 2.
• Signal Circuit Trouble Memory - facilitates quick
identification of an intermittent/fault (short circuit, open
or ground) which has previously occurred on one or
more signaling circuit outputs. LEDs indicate/identify
which output the fault has occurred.
• Common trouble input and output.
• Ground fault detection.
• Unit includes power supply, logic board enclosure,
cam lock, and battery leads.
Enclosure Dimensions (approx. H x W x D):
18” x 14.5” x 4.625” (457.2mm x 368.3mm x 117.48mm)
Overview:
The Altronix AL842ULADA is an extremely cost effective 8 amp remote power supply/battery charger. It may be con-
nected to any 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC
such as strobes and horns) expansion support to meet ADA requirements. It also provides auxiliary power to support system
accessories. The unit delivers electronically regulated and filtered 24 volt power to Class B, Style W, Y or Class A, Style
Z NAC loop circuits. Additionally, a separate 1 amp auxiliary output for 4-wire smoke detectors is available. The 8 amp
max. alarm current can be divided between the four (4) outputs for powering NAC devices. Each output is rated at 2.5 amp
max., and can be independently programmed for Steady, Temporal Code 3 or Strobe Synchronization. All outputs may
be programmed for Input to Output Follower Mode (output will follow input). In non-alarm condition independent loop
supervision for Class A, Style Z and/or Class B, Style W, Y FACP NAC circuits is provided. In the event of a loop trouble,
the FACP will be notified via the steered input (input 1 or input 2). In addition, there are common trouble output terminals
[NC, C, NO] which are used to indicate general loop/system trouble. A common trouble input is provided for optional [NC]
(normally closed) devices to report trouble to the FACP. Two (2) FACP signaling outputs can be employed and directed
to control supervision and power delivery to any combination of the four (4) outputs.
Specifications:
AL842ULADA - NAC Power Extender
