- 10 - AL842ULADA

Appendix A - UL Listed Compatible Devices

A.1 Four (4) Wire Smoke Detectors

Table A-1 below lists four (4) wire smoke detectors compatible with AL842ULADA AUX output.

Smoke Detector/Base

Detector Type

Max Standby

Current (mA)

Alarm

Current (mA)

System Sensor B112LP

Base

0.12

36

System Sensor B114LP

Base

*

*

System Sensor B404B

Base

*

*

System Sensor DH100ACDC

Photoelectric

0.15

0.70

System Sensor DH100ACDCLP

Photoelectric

0.15

0.70

System Sensor DH100ACDCLPW

Photoelectric

0.15

0.70

System Sensor DH400ACDCI

Ionization Duct

25

95

System Sensor DH400ACDCP

Photoelectric Duct

25

95

System Sensor 1112/24/D

Ionization

0.05

50

System Sensor 1424

Ionization

0.10

41

System Sensor 1451 (w/B402B Base)

Ionization

0.10

39

System Sensor 2112/24ATR

Photoelectric

0.50

60/70

System Sensor 2112/24AITR

Photoelectric

0.50

60/70

System Sensor 2112/24/D

Photoelectric

0.05

50

System Sensor 2112/24R

Photoelectric

0.50

60/70

System Sensor 2112/24TR

Photoelectric

0.50

60/70

System Sensor 2112/24T/D

Photoelectric w/135

o

Thermal

0.05

50

System Sensor 2112/24TSRB

Photoelectric w/135

o

Thermal Supervisory Relay

15

45

System Sensor 2312/24TB

Photoelectric

0.12

50

System Sensor 2412 (12 volt)

Photoelectric

0.12

77

System Sensor 2412AT (12 volt)

Photoelectric

0.12

58

System Sensor 2412TH (12 volt)

Photoelectric

0.12

77

System Sensor 2424

Photoelectric

0.10

41

System Sensor 2424TH

Photoelectric

0.10

41

System Sensor 2451

Photoelectric

0.10

39

System Sensor 2451TH (with/B402B Base)

Photoelectric

0.10

39

System Sensor 2W-MOD

Loop Test/Maintence Mod.

30

50
