Altronix SMP10PMC24X Installation Instructions - Manual (Page 4)

Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
Altronix Corp.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
web site: www.altronix.com, e-mail: [email protected], Made in U.S.A.
IISMP10C24X - Rev. 102003
C11D
.875"
1"
0
0 0
0
10.75"
1.5" 6" 10.5"
2"
0 1.25" 4.5" 12"
15.5"
4.5"
4.5"
1.25"
1.25"
14.25"
13.5"
10"
6.625"
TOP & BOTTOM
Enclosure Dimensions for:
15.5”H x 12”W x 4.5”D
Enclosure accomodates up to two (2)
12VDC/12AH batteries.
- 4 -
