- 2 - Tempo2
7. Depress Advance twice SU 00:00 will appear in display.
TestTime
8. Depress and Hold Confirm SU 00:00 will appear in display.
for two (2) seconds Test day
Enter the desired day of the week by depressing Advance to make the selection
(MO-SU or ** for every day test).
9. Depress Confirm SU 00:00 will appear in display.
TestHour
Enter the desired hour of day by depressing Advance to make the selection.
10. Depress Confirm SU 00:00 will appear in display.
Test min
Enter the desired min of day by depressing Advance to make the selection.
11. Depress Confirm pulse= 1 will appear in display.
Duration
Depress Advance to select duration of relay operation (1-60 seconds),
then depress Confirm to accept.
Trigger Mode Programming:
1. Depress Advance 00:00:00 will appear in display.
Change ?
2. Depress and Hold Confirm 00:00:00 will appear in display.
for 2 seconds until SetDelay
Enter the desired amount of hours by depressing Advance to make the selection.
3. Depress Confirm 00:00:00 will appear in display.
SetDelay
Enter the desired amount of minutes by depressing Advance to make the selection.
4. Depress Confirm 00:00:00 will appear in display.
SetDelay
Enter the desired amount of seconds by depressing Advance to make the selection.
5. Depress Confirm pulse = 1 will appear in display.
Set PLS
Depress Advance to select pulse duration (1-60 seconds). If pulse is not needed skip to step 6.
6. Depress Confirm TRIG_OFF will appear in display.
TRG_EDGE
Enter the desired trigger option (OFF, ON, CNG) by depressing Advance to make the selection.
Removal of trigger will start time cycle.
OFF option starts timing cycle when trigger is removed.
ON option starts timing cycle when trigger is applied.
CNG option starts timing cycle when trigger is removed or applied.
7. Depress Confirm RLY = ON will appear in display.
Event
Enter the desired relay option (OFF, ON, PLS) by depressing Advance to make the selection.
OFF option - relay turns off at the end of timing cycle.
ON option - relay energizes at the end of timing cycle.
Pulse option - relay energizes momentarily (1 to 60 sec).
Depress Confirm to accept .
