eFlow4N Series

Overview:

The eFlow4N power supply/chargers convert a 120VAC / 60Hz input to a 12VDC or 24VDC nominal output
(see Power Supply Configuration Reference Chart and Specifications).

eFlow4N Series Power Supply Configuration Reference Chart:

Altronix Model Number

Nominal DC Outputs

Maximum Supply Current for Main and Aux. Outputs(amp)

Power-Limited Output

Input Rating: 120VAC, 60Hz

Input Fuse Rating

Battery Fuse Rating

Ripple Voltage (mV)

Under low battery condition

Power Distribution Modiule

Number of Outputs

Fused Outputs Ratings

PTC Outputs Ratings

Accommodates up to 7AH Batteries

Accommodates up to 12AH Batteries

[DC]

[AUX]

12VDC Output Range (volts)

24VDC Output Range (volts)

12VDC Output Range (volts)

24VDC Output Range (volts)

eFlow4N

10.1-

13.2

20.28-

26.4

10.05-

13.2

20.2-

26.4

4A

3

3.5A

5A/250V

5A/32V

730

N/A

1

3

eFlow4NX

3

eFlow4N8

10.1-

13.2

20.28-

26.4

10.05-

13.2

20.2-

26.4

4A

3

3.5A

5A/250V

5A/32V

730

PD8UL

8

2.5A

3

eFlow4NX8

2.5A

3

eFlow4N8D

9.78-

13.2

20.0-

26.4

10.05-

13.2

20.2-

26.4

4A

3

3.5A

5A/250V

5A/32V

730

PD8ULCB

8

2A

3

eFlow4NX8D

2A

3

These units are classified as Power-Limited stand alone power supplies with stand-by battery and they are suitable to power: sensors,
electro-mechanical devices (e.g. electric door strikes) defined in the National Electrical Code/NFPA70/NFPA72 and the Canadian Electri-
cal Code, Part 1.

UL Listings for US Installations:
UL 294 - UL Listed for Access Control System Units.
UL 603 - UL Listed for Power Supplies for Use with Burglar-Alarms Systems.
UL 1481 - UL Listed for Power Supplies for Fire Protective Signaling Systems.
UL Listings for Canadian Installations:
ULC-S318-96 - Power Supplies for Burglar Alarm Systems. Also suitable for Access Control.

California State Fire Marshal

(eFlow4N and eFlow4NX only)

CE Approved

Stand-by Specifications:

Battery

Burg. Applications

4 hr. Stand-by/

15 min. Alarm

Fire Applications

24 hr. Stand-by/

5 min. Alarm

Access Control

Applications

Stand-by

7AH

0.4 amp/4 amp

N/A

15 Mins./4 amp

12AH

1 amp/4 amp

0.3 amp/4 amp

35 Mins./4 amp

40AH (for eFlow4NX refer to Fig. 7, pg. 10)

4 amp/4 amp

1.2 amp/4 amp

Over 4 Hours/4 amp

65AH (for eFlow4NX refer to Fig. 7, pg. 10)

4 amp/4 amp

1.5 amp/4 amp

Over 4 Hours/4 amp
