6 Set up with the display and adjustment module
VEGAFLEX 82 • Profibus PA
44220-EN-130910
Menu item Default value Modified value
Accept adjustment of the level measurement? Yes
Max. adjustment - Interface 100 %
Max. adjustment - Interface Distance: 0.000 m(d) - note block-
ing distances
Min. adjustment - Interface 0 %
Min. adjustment - Interface Distance: Probe length - take dead
band into account
Integration time - Level 0.0 s
Integration time - Interface 0.0 s
Linearization type Linear
Linearization - Socket correction 0 mm
Linearization - Vessel height Probe length
AI FB1 Tag Descriptor
AI FB1 Channel
Primary Value (lin. percent level)
AI FB1 scaling PV Scale (min.) 0 %
AI FB1 scaling PV Scale (max.) 100 %
AI FB1 Lin. Type Linear
AI FB1 Out Scale Unit %
AI FB1 Out Scale Decimal Point #.##
AI FB1 Out Scale (min.) 0 %
AI FB1 Out Scale (max.) 100 %
AI FB1 PV FTime 0 s
AI FB1 Hi Hi Limit 3.402823E+38 %
AI FB1 Hi Limit 3.402823E+38 %
AI FB1 Lo Lo Limit -3.402823E+38 %
AI FB1 Lo Limit -3.402823E+38 %
AI FB1 Hysteresis 0.50 %
AI FB1 Fail Safe Mode (behaviour in case of mal-
function)
Last Valid Out Value (last valid
measured value)
AI FB1 Fail Safe Value 0.00 %
AI FB1 Target Mode Auto
Display
Menu item Default value Modified value
Language Order-specific
Displayed value 1 Filling height Level
Displayed value 2 Electronics temperature
Backlight Switched off
