6 Set up with the display and adjustment module
VEGAFLEX 82 • Profibus PA
44220-EN-130910
With a reset, certain parameter adjustments carried out by the user
are reset.
The following reset functions are available:
Delivery status: Restoring the parameter settings at the time of ship-
ment from the factory incl. the order-specific settings. A created false
signal suppression, user-programmable linearization curve as well as
the measured value memory will be deleted.
Basic settings: Resetting of the parameter settings incl. special
parameters to the default values (presettings) of the respective instru-
ment. Any created false signal suppression or user-programmable lin-
earization curve as well as the measured value memory are deleted.
The following table shows the default values of the instrument. De-
pending on the instrument version or application, all menu items may
not be available or some may be differently assigned:
Setup
Menu item Default value Modified value
Block adjustment Released
Measurement loop name Sensor
Units Distance unit: mm
Temperature unit: °C
Probe length Length of the probe Ex factory
Type of medium Bulk solid
Application Level in the metallic vessel
Medium, dielectric constant Granules, powder, cement /
1.5 … 3
Superimposed gas phase Yes
Dielectric constant, upper medium (TS) 1.5
Tube inner diameter 200 mm
Max. adjustment - Level 100 %
Max. adjustment - Level Distance: 0.000 m(d) - note block-
ing distances
Min. adjustment - Level 0 %
Min. adjustment - Level Distance: Probe length - take dead
band into account
Additional adjustments
- Reset
