Seal between housing and housing
cover NBR (stainless steel housing), silicone (Alu/plastic
housing)
-
Ground terminal 316L
Sensor length See chapter "Dimensions"
Weight
-
Instrument weight (depending on proc-
ess fitting) 0.8 … 4 kg (0.18 … 8.82 lbs)
-
Weight - External housing 0.7 … 1.5 kg (1.543 … 3.307 lbs), depending on
housing material
Process fittings
-
Pipe thread, cylindrical (ISO 228 T1) G 1½ A
-
American pipe thread, tapered 1½ NPT
-
Flanges DIN from DN 50, ANSI from 2"
-
Mounting adapter G 2 A or 2 NPT
Frequency range K band, 24.085 GHz (ISM band)
Measuring range 0.1 … 100 m (0.33 … 328 ft)
Beam angle 1)
-
Threaded version - internal horn antenna
(PTFE cover) 20 °
-
Plastic encapsulated antenna with PP
cover 10 °
-
Horn antenna (316L) - ø 40 mm (1.575 in) 22 °
-
Horn antenna (316L) - ø 48 mm (1.89 in) 18 °
-
Encapsulated antenna with PTFE cover -
Flange DN 50, ANSI 2" 18 °
-
Encapsulated antenna with PTFE cover -
Flange DN 80 … DN 150, ANSI 3" … 6" 10 °
Output variable
Output Floating transistor output 2)
Load current < 400 mA
Voltage loss < 0.5 V
Turn-on voltage < 55 V DC
Blocking current < 10 µA
Modes (switchable) min./max.
Measuring accuracy
Hysteresis approximately 1 dB
1) Outside the specified beam angle, the energy of the radar signal has a level
of -3 dB (50 %)
2) Not overload resistant and not short-circuit proof
