52
10 Supplement
VEGABAR 86 • HART and accumulator pack
45040-EN-131107
Process conditions
Product temperature depending on the measuring cell seal
The specifications are an overview. The specification on the type plate are valid.
Version Measuring cell seal Product temperature
Suspension cable PE FKM (VP2/A)
EPDM (A+P 75.5/KW75F) -20 … +60 °C (-4 … +140 °F)
Suspension cable PUR FKM (VP2/A)
EPDM (A+P 75.5/KW75F) -20 … +80 °C (-4 … +176 °F)
Suspension cable FEP FKM (VP2/A)
EPDM (A+P 75.5/KW75F) -20 … +100 °C (-4 … +212 °F)
FFKM (Kalrez 6375) -10 … +100 °C (+14 … +212 °F)
Connection tube FKM (VP2/A)
EPDM (A+P 75.5/KW75F) -20 … +100 °C (-4 … +212 °F)
FFKM (Kalrez 6375) -10 … +100 °C (+14 … +212 °F)
Transmitter material PVDF FKM (VP2/A)
EPDM (A+P 75.5/KW75F) -20 … +60 °C (-4 … +140 °F)
FFKM (Kalrez 6375) -10 … +60 °C (+14 … +140 °F)
Transmitter protection PE FKM (VP2/A)
EPDM (A+P 75.5/KW75F) -20 … +60 °C (-4 … +140 °F)
Mechanical stress, depending on the instrument version
Vibration resistance
Ʋ Suspension cable 4 g at 5 … 200 Hz according to EN 60068-2-6 (vibration
with resonance)
Ʋ Connection tube 1 g (with lengths > 0.5 m (1.64 ft), the tube must be sup-
ported in addition)
Shock resistance 100 g, 6 ms according to EN 60068-2-27 (mechanical
shock)
Electromechanical data - version IP 66/IP 67 and IP 66/IP 68; 0.2 bar
Options of the cable entry
Ʋ Cable gland M20 x 1.5
Ʋ Cable diameter (options) 5 … 9 mm (0.20 … 0.35 in)
6 … 12 mm (0.24 … 0.47 in)
10 … 14 mm (0.39 … 0.55 in)
Ʋ Cable entry ½ NPT
Ʋ Blind plug M20 x 1.5; ½ NPT
Ʋ Closing cap M20 x 1.5; ½ NPT
Plug options
Ʋ Signal circuit Plug M12 x 1, according to ISO 4400, Harting HAN,
7/8" FF
Ʋ Indication circuit M12 x 1 plug
