10 Supplement
VEGABAR 86 • HART and accumulator pack
45040-EN-131107
Nominal range Overload capacity, max.
pressure
Overload capacity, min. pres-
sure
0 … 25 bar/0 … 2500 kPa 130 bar/13000 kPa 0 bar abs.
Nominal measuring ranges and overload capacity in psi
The specifications are only an overview and refer to the measuring cell. Limitations due to the
material and version of the process fitting as well as the selected pressure type are possible. The
specifications on the nameplate apply.
Nominal range Overload capacity, max.
pressure
Overload capacity, min. pres-
sure
Gauge pressure
0 … +0.4 psig
+75 psig -0.725 psig
0 … +1.5 psig +225 psig -2.901 psig
0 … +5 psig +435 psig -11.60 psig
0 … +15 psig +510 psig -14.51 psig
0 … +30 psig +725 psig -14.51 psig
0 … +150 psig +1300 psig -14.51 psig
0 … +300 psig +1900 psig -14.51 psig
Absolute pressure
0 … 1.5 psi
225 psig 0 psi
0 … 5 psi 435 psi 0 psi
0 … 15 psi 510 psi 0 psi
0 … 30 psi 725 psi 0 psi
0 … 150 psi 1300 psi 0 psi
0 … 300 psi 1900 psi 0 psi
Reference conditions and actuating variables (according to DIN EN 60770-1)
Reference conditions according to DIN EN 61298-1
Ʋ Temperature +15 … +25 °C (+59 … +77 °F)
Ʋ Relative humidity 45 … 75 %
Ʋ Air pressure 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psig)
Determination of characteristics Limit point adjustment according to IEC 61298-2
Characterstic curve Linear
Reference installation position upright, diaphragm points downward
Influence of the installation position < 0.2 mbar/20 Pa (0.003 psig)
Deviation (according to IEC 60770)
Applies to the digital signal output (HART, Profibus PA, Foundation Fieldbus) as well as to the
analogue current output 4 … 20 mA and refers to the set span. Turn down (TD) is the ratio nominal
measuring range/set span.
The specified values correspond to the value F
Kl
in chapter "Calculation of the total deviation".
