6 Adjustment with the display and adjustment module PLICSCOM
VEGADIF 65 • Foundation Fieldbus
36130-EN-130417
▶ Basic adjustment
Display
Diagnostics
Service
Info
2. Confirm the menu "Basic adjustment" with [OK].
Applications
Level
▼
3. Confirm the menu item "Application" with [OK].
Warning:
Note the warning: "Output can change".
4. Select with [->] "OK" and confirm with [OK].
5. Select the requested application in the selection list, for example
"Flow" and confirm with [OK].
In this menu item you select the adjustment unit as well as the unit for
the temperature indication in the display.
To select the adjustment unit (in the example switching over from
mbar to bar), proceed as follows:
1. Push the [OK] button in the measured value display, the menu
overview is displayed.
▶
Basic adjustment
Display
Diagnostics
Service
Info
2. Confirm the menu "Basic adjustment" with [OK], the menu item
"Unit" will be displayed.
Unit
Unit of measurement
mbar
▼
Temperature unit
°C
▼
3. Activate the selection with [OK] and select "Units of measure-
ment with [->].
4. Activate the selection with [OK] and select the requested unit with
[->] (in the example bar).
5. Confirm with [OK] and move to position correction with [->].
The adjustment unit is thus switched over from mbar to bar.
Information:
When switching over to adjustment in a height unit (for example for
level measurement), the density also has to be entered.
Proceed as follows to enter the density:
1. Push the [OK] button in the measured value display, the menu
overview is displayed.
Unit of measurement
