3 Product description
VEGADIF 65 • Foundation Fieldbus
36130-EN-130417
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
•
Not in the open
•
Dry and dust free
•
Not exposed to corrosive media
•
Protected against solar radiation
•
Avoiding mechanical shock and vibration
•
Storage and transport temperature see chapter "Supplement -
Technical data - Ambient conditions"
•
Relative humidity 20 … 85 %
3.5 Accessories and replacement parts
The display and adjustment module PLICSCOM is used for measured
value indication, adjustment and diagnosis. It can be inserted into the
sensor and removed at any time.
You can find further information in the operating instructions "Display
and adjustment module PLICSCOM" (Document-ID 27835).
The interface adapter VEGACONNECT 4 enables the connection of
communication-capable instruments to the USB interface of a PC. For
parameter adjustment of these instruments, an adjustment software
such as PACTware with VEGA-DTM is required.
You can find further information in the operating instructions "Interface
adapter VEGACONNECT" (Document-ID 32628).
VEGADIS 61 is suitable for external measured value indication and
adjustment of plics® sensors. It is connected to the sensor with an up
to 25 m long, four-wire, screened standard cable.
You can find further information in the operating instructions "VE-
GADIS 61" (Document-ID 27720).
The protective cover protects the sensor housing against soiling and
intense heat from solar radiation.
You will find additional information in the supplementary instructions
manual "Protective cover" (Document-ID 34296).
The oval flange adapter enables the connection of a ½ NPT tube to a
VEGADIF 65 or a valve block. By selecting the suitable materials, the
oval flange adapter can be adapted to all processes.
You can find additional information in the supplementary instructions
"Mounting accessory pressure" (Document-ID 43478).
Valve blocks enable simple installation and setup of a differential
pressure transmitter. When the process valves are closed, the equali-
zation valve enables a pressure compensation for the measuring
Storage
Storage and transport
temperature
Display and adjustment
module
Interface adapter
External display and
adjustment unit
Protective cap
Oval flange adapter
Valve blocks
