Solder the transistor leads
Repeat for the remaining transistor T9 (TIP142)
Fixing Diode D15
Bend the leads as indicated.
Put a large drop of heat conductive
compound on the heatsink.
Solder the diode to the two outer pins of
the pin header.
Make sure that the diode is bend to-
wards the heat conductive com-
pound.
Mind the direction of the ring. It should
face transistor T9
27. Fitting diode D15 (1N4007)
!
