Spicer Steer Axles Illustrated Parts List User Manual
Page 23

EFA Family Steer Arms
21
18F3, 20F4, 22T2/T5, 24T2/T5 Steer Arms
D
B
C
A
Part No.
E
Type
1.047
1.300
.75
7.81 820505
Shown
“T”
820506
Opposite
“T”
8.36 820501
Shown
“T”
820503
Opposite
“T”
8.81 820502
Shown
“T”
820504
Opposite
“T”
9.81 820509
Shown
“T”
820511
Opposite
“T”
10.81 820510
Shown
“T”
820512
Opposite
“T”
12.37 820516
Shown
“T”
820517
Opposite
“T”
13.81
820515
Shown
“T”
3.76
7.25 820687
Shown
“T”
821835
Shown
“S”
8.25 820688
Shown
“T”
820689
Shown
“S”
