EFA Family Steer Axle Components
10
EFA18F3, EFA20F4, EFA22T2/T5 and EFA24T2/T5 Parts List
Item No. Part Name Qty. Per Axle Part No. Remarks
1 Lubrication Fitting 4 1001414* 90° Elbow
2 Hex Bolt 16 1004790*
3 Washer 16 1004815*
4 Knuckle Cap 4 820584*
5 Bushing (81786 Bronze) 4 806334*
6 Knuckle Pin 2 806333* Length 9.95", Dia 1.75"
7 Washer 2 820600
8 Hex Nut 2 820720
9 Cotter Pin 2 821237
10 Cotter Pin Varies 1004797
11 Hex Nut Varies 821205
12 Seal 4 820518*
13 Knuckle Shims .005" A/R 820596*
.010" A/R 820587*
.015" A/R 820598
.020" A/R 820599*
.030" A/R 811522*
14 Thrust Bearing 2 811523*
15 Draw Key 2 820587*
16 Prevailing Torque-type Locknut 2 1004804*
17 Stop Screw 2 821316* 26°-34° Wheel Cut
18 Hex Locknut 2 821336*
19 Cotter Pin 2 1004805
20 Woodruff Key Varies 820588
21 Steer Arm Ball Stud Varies 820339
22 Ball Stud Nut Varies 820724
23 Ball Stud Cotter Key Varies 90556
Gasket Compound A/R 107276*
KIT - KNUCKLE PIN REPLACEMENT
(services one axle) 1 811525* Includes parts with*
* Items included in kit.
