EFA Family Steer Axle Components
8
Note:
For proper removal and installation of steer knuckle bushings and seals, use Spicer installation tool part number 700291.
EFA12F4 and EFA13F5 Parts List
Item
No.
Part Name
Qty. Per Axle
12F4
Part No.
13F5
Part No
Remarks
1
Lubrication Fitting
2
1001414*
1001414*
90° Elbow
2
Hex Bolt
12
1004790*
1004790*
3
Washer
12 1004815*
1004815*
4
Knuckle Cap
4
1004779
1004779
5
Knuckle Cap Gasket
4
1004785*
1004785*
6
Bushing
4
1008924*
1008924*
7
Knuckle Pin
2
1009304*
1009304*
8
Washer
2
1005726
1005726
9 Hex
Nut
2
1005725
1005725
10
Cotter Pin
2
1005727
1005727
11
Cotter Pin
3
1004797
1004797
12
Hex Nut
3
1004787
1004787
13
Seal
4
1004783*
1004783*
14
Knuckle Shims
.005"
A/R
1004800*
1004800*
.010"
A/R
1004801*
1004801*
.015"
A/R
1004802*
1004802*
.020"
A/R 1004803*
1004803*
15
Thrust Bearing
2
1008360*
1008360*
16
Draw Key
2
816239
816239
17
Prevailing Torque-type Locknut
2
1004804*
1004804*
18
Stop Screw
2
1/2” Thread
1006107
5/8” Thread
807783
25° - 34° Wheel Cut
1008888
807782
30° - 40° Wheel Cut
1006256
807781
35° - 45° Wheel Cut
807780
40° - 50° Wheel Cut
19
Hex Locknut
2
1004793
821336
20
Lubricating Fitting
2
1003998*
1003998*
Straight
806661
45°
21
Cotter Pin
2
1004805
1004805
22
Woodruff Key
3
1004784
1004784
KIT - KNUCKLE PIN
REPLACEMENT
(services one axle)
1
806355*
806355*
Includes parts with*
* Items included in kit.
{
{
