Parts Listing
47
(1) See "Bill of Material Table" on next page
(2) See "Variable Parts Table" within this section
(3) Contact Vehicle Manufacturer
(4) Not Sold Separately
(6) See Shim Table in the back of this catalog
(9) NOTE: When replacing a model 80/286 Power-Lok component or case assembly, the complete Power-Lok case assembly or
component must be replaced with a Track-Lok case assembly. The only Power-Lok component currently available is disc and
plate kit 701129X.
X510-5
ITEM PART
DESCRIPTION
NO. NUMBER
ITEM PART
DESCRIPTION
NO. NUMBER
1 -(3) Housing - Axle Service
2 -(1) Drive Pinion & Gear Assembly
3 707065X KIT - Inner Pinion Bearing
707066X PKG - Pinion Bearing Shim
(inc items 4, 5, 11, 12)
708036 PKG - Diff & Pinion Bearing Shim
(inc items 4, 5, 11, 12, 21)
4 -(4) Inner Pinion Bearing Shims
5 -(4) Outer Pinion Bearing Shims
6 707064X KIT - Outer Pinion Bearing
7 42430 Thrustwasher - Bearing
8 -(2) Seal - Pinion Oil
9 -(2) Seal - Deflector
9A -(2) Seal - V-Ring
10 -(2) End Yoke Assembly
11 37104 Washer - Pinion Nut
12 37082 Pinion Nut
-(2) KIT - Carrier Cover
(inc items 13, 14, 15, 16)
13 -(2) Carrier Cover
14 38637 Plug - Carrier Cover
15 -(2) Bolt - Carrier Cover
16 38615 RTV Silicone Sealant
17 -(3) Differential Bearing Cap
18 48632-1 Bolt - Differential Bearing Cap
19 707069X KIT - Outboard Bearing Spacer
20 706070X KIT - Differential Bearing
21 708035(6) PKG - Differential Bearing Shim
22 -(1) Case - Differential (std)
23 42413 Pinion - Differential (std)
24 35082 Thrustwasher - Differential Pinion
25 42411 Gear - Differential (std)
26 34729 Thrustwasher - Differential Gear
27 46640 Shaft - Differential
28 47024 Lock - Differential Shaft
29 42433 Bolt - Drive Gear
30 42414 Tone Ring (ABS)
31 -(2) Seal - Inner Wheel
32 -(3) Bearing - Inner Wheel
33 -(3) Hub Assembly
34 -(3) Bearing - Outer Wheel
35 47163 Spindle Nut
36 46545 Locking Wedge
37 39697 Gasket
38 -(1) Axle Shaft
39 45720 Screw - Flange Head
40 -(1) Case - Differential
41 41610-1 Screw - Flange Head
42 47802 Shaft - Differential (t/l)
43 47798 Pinion - Differential (t/l)
44 47796 Gear - Differential (t/l)
701129X KIT - Diff Plate & Disc (p/l)
2003819 KIT - Diff Plate & Disc (t/l)
45 -(4) Disc - Differential Dished
46 -(4) Plate - Diff Pressure
47 -(4) Disc - Diff Clutch
48 47800 Thrustwasher - Pinion Diff (t/l)
Chrysler/Dodge 80/286 Rear
